GVM -SD300D Instruction Manual page 13

④ Adjust color temperature (CCT): Range 2700K~7500K
Rotate mode or master mode: Switch to color temperature adjustment by pressing
the composite knob, and turn the composite knob to adjust the color temperature.
APP mode: connect to the APP and adjust the color temperature through the APP.
In DMX mode, adjust the color temperature through the DMX console.
⑤ Channel adjustment (CH): Range 1~12
In slave mode / APP mode / DMX mode, turn the composite knob to change the
channel number.
APP mode: connect to the APP and set the value of the channel through the APP.
⑥ APP control:
Set the mode to APP mode, turn on the GVMLED phone APP, in the Bluetooth
setting page, find the device with the Bluetooth name BT_LED and connect, Wait for
the connection. After the connection is successful, the light can be controlled
through the APP.
⑦ Adjust scene (SC): Range 1~8
There are 8 kinds of scenes in scene mode: Lightning, Strobe, Candle, TV, Bad Bulb,
Explosion, Fireworks, Paparazzi.
Press and hold for 2 seconds to switch to the lighting mode SCENE → short press
the composite knob to switch → turn the composite knob to select between the
different scene mode and adjust the brightness/color temperature parameters.
In the APP mode, connect to the APP and adjust the scene through the APP.
⑧ DMX control:
Connect the DMX console to the LED light through the DMX input and set the light
and DMX console to the same channel, so that the light can be controlled through
the DMX console.
⑨ Online control: (Joint control between lights)
Prepare two or more video lights, set one light to master mode, and the others to
slave mode, and then set all the video lights to the same channel. After that, you
can control the brightness of the slaved lights by adjusting the brightness of the
master light, synchronizing the master light and the slaved lights.
You also can use the APP to connect to the master light and control the slaved
light through the APP.
