USER INTERFACE

Presets:
Controls:

INPUTS AND OUTPUTS

Audio inputs:
Audio outputs:
GPIO Ports/Standby Input
RDNet:
USB (control/firmware update):

POWER SUPPLY SPECIFICATIONS (CONSUMPTION)

Consumption at 1/8 of the power
under
normal operating conditions (*):
Consumption at 1/3 of the power
under
maximum operating conditions (**):
Consumption with speaker on and
no signal (idle):
Inrush current:
* NOTE FOR THE INSTALLER: Values refer to 1/8 of the power under normal operating conditions (musical program with rare or no clipping).
For any configuration type, we recommend considering them to be the minimum values for dimensioning.
** NOTE FOR THE INSTALLER: Values refer to 1/3 of the power under heavy operating conditions (musical program with frequent clipping
and limiting). We recommend dimensioning in accordance with these values for professional installations and tours.

DIMENSIONS AND WEIGHT

Width:
Height:
Depth:
Weight:
Product features, specifications and appearance are subject to change without prior notice. dBTechnologies reserves the
right to make changes or improvements in design or manufacturing without any obligation to change or improve previously
manufactured products.
IA3204R
50
Flat, dB Technologies speaker, User preset
Reset button
4x Analogue (3.81mm Euroblock)
4x Analogue (5.08mm Euroblock)
3.81mm Euroblock
RJ45 Data In/Data Out
1x type B USB
2.2 A (220 - 240V~) - 4.2 A (100 - 120V~)
5 A (220 - 240 V~) - 10 A (100 - 120 V~)
0.32 A (220 - 240 V~) - 0.34 A (100 - 120 V~)
9.4 A
440 mm (17.3 inch.)
88 mm (3.5 inch.)
305 mm (12 inch.)
8.3 kg (18.3 lbs.)
