4. EXAMPLES OF USE

Below there are some common examples of how the IA3204R amplifier can be used.

INPUT WIRING

BALANCED ANALOGUE INPUT

Connect the input signal positive, negative
and ground to the corresponding pins on the
amplifier input you want, as indicated by the
label.

UNBALANCED ANALOGUE INPUT

Connect the signal positive and ground
(connected to negative) to the corresponding
pins on the amplifier input.

OUTPUT WIRING

STEREO SETUP

Connecting a pair of speakers in stereo mode.
Load the correct setup from the Setup => Output
section of AURORA NET. The impedance must be
4 Ohm or greater.
IA3204R
44
O U T 2
+ B R I D G E
O U T 1 O U T 2
O U T 3 O U T 4
+ B R I D G E
S T E R E O S e t u p
+ B R I D G E
O U T 1 O U T 2
O U T 3 O U T 4
+ B R I D G E
English
O U T 1
I N 1 I N 2 I N 3 I N 4
D e f a u l t I n p u t C o n f i g u r a t i o n
M i n i m u m i n p e d a n c e
4 o m h
D o n ' t c o n n e c t a n y
O u t p u t t o G r o u n d
O U T 1
I N 1 I N 2 I N 3 I N 4
Cod. 420120450 REV. 1.0
D e f a u l t B r i d g e I n p u t C o n f i g u r a t i o n
M i n i m u m i n p e d a n c e
8 o m h
D o n ' t c o n n e c t a n y
O u t p u t t o G r o u n d
