GPIO

From the GPIO section, you can click the Configure button to customise the behaviour of the GPIO ports; some
configuration examples are given in the
The default GPIO status is given below.
GPIO 1
GPIO 2
GPIO 3
GPIO 4
IA3204R
40
EXAMPLES OF USE
Configuration Action
Analogue Gain
Analogue Gain
Analogue Gain
Analogue Gain
chapter in this manual.
Object Channel
Processing CH A
Processing CH B
Processing CH C
Processing CH D
