Automatic Systems TRS 372 Technical Manual page 52

8.6. SERVICE
Every month (See
note opposite)
300,000 cycles
1,000,000 cycles
5 years
Check that the door is stable (floor attachment).
If motorisation: check the belt tension.
Clean the head unit, vertical uprights and rotating obstacle with water and a non-aggressive
detergent (non-chlorinated in particular).
If the AISI 304 stainless-steel option has been chosen for the mobile obstacle, clean with a product
for cleaning stainless steel. Automatic Systems can supply an approved product under part number
0/6031/000.
Repair any chips, dents or scratches on the painted surfaces of the equipment.
Service frequency must be adapted to the conditions in which the door is used,
particularly if it is installed in an oxidising atmosphere: at the entrance to a swimming
pool (heated and chlorinated atmosphere), at a beach, in an industrial environment,
etc.
Replace the springs (0/0208/042) (C) in both electromagnets as they may break due to wear.
Replace the shock absorber (Item N, Fig. 6, page 13), which becomes less effective with wear.
If motorisation: check the condition and tension of the belt.
Check that all bolts on the mechanical parts and supporting structure are tight.
Spray the pivots on the lock bolt with silicone spray (P/N 0/7508/284).
Replace the battery of the AS1635 control logic: 3 V/48 mA lithium battery.
Automatic Systems can supply an approved product under part number 0/7111/010.
To access the battery, remove the access panel inside the head unit and remove the cover from the
front panel of the logic assembly by unscrewing the four screws.
C
50
