6. BOILER PACKAGING

CAUTION:
- The device is delivered with a cartonboard with dimensions of 735 x 345 x 490 (HxWxD) mm, supported by
upper and lower styrofoams.
- Parts required for installation of the device (wall bracket, 5 gaskets for HM and HCH and 6 gaskets for HST
water and gas connections, 3 anchors and 3 fixing screws) are placed on the top styrofoam.
- The hermetic flue set is delivered in a carton box separate from the unit. The standard hermetic flue set
(Ø60/100 or Ø80/125) consists of the following components (Figure 6).
3
2
Attention must be paid to warning on packaging regarding handling and storage.
1
5
4
7
6
Figure 5
8
Figure 6
10
Assembly Bracket
10
9
