10.2. Using the Device
10.2.1. Switching off the Device
You can switch off the boiler by holding down the ON/ OFF button for 3 seconds. LCD light will be OFF after 1
minute.
Anti-freeze function remains active.

11- CONTROL PANEL

11.1- Functions of Buttons

The control panel consists of the relevant elements as shown in figure 17 below.
1
Position Selection Button
The position can be changed by pressing the position selection button once to change between the winter
mode and the summer mode. If the button is pressed for 3 seconds, the device will switches into "standby"
position. It will suffice to press the button once to get the device in operation position.
2
Reset Button
Main functions:
• Exit from lockout error (EXX)
• ECO mode activation
Comfort mode activation
•
When your device fails, the error code will start flashing on the display. There are 2 types of errors, lockout
(EXX) and blocking (FXX) error. When a lockout error condition occurs (EXX), the error must first be corrected
so that the error code can be removed from the LCD screen. After pressing the "Reset" key once, the device
can switch back to normal operation state. As for a blocking error, the fault cannot be removed from the LCD
display pressing the "Reset" button (FXX). When this error is corrected, error code is automatically disappears
from LCD screen. The first time the device starts, it will start working in Comfort mode.
Once the Reset button is pressed when operating in Comfort mode, the device will switch to Eco mode. Then
when Reset button is pressed again, the unit will switch to Comfort mode.
Figure 17 Control Panel
