E.C.A. CALORA PREMIX Installation And User's Operating Instructions page 12

7.3. Distances for Placement of Flues
POSITION
A-Below a windows
B- Below an air vent
C- Below rain channel
D- Under the balcony
E- Next to a window
F- Next to an air grill
Places where it is undesirable to install the chimney outlet of type C (hermetic) devices are stated in the
following articles:
- Passages and corridors,
- Narrow eaves gaps,
- Ventilation and light spaces of buildings,
- Inner parts of balconies,
- Elevator shafts,
- Vents that provide fresh air to other units,
- In places that may be directly exposed to wind resistance.
Underground, basement etc. chimneys of the products installed in the spaces; It should be installed in a way that
it will not endanger living spaces and that no person can intervene. If such an installation is not possible, the
chimney outlet should be extended to the roof.
Figure 8
DISTANCE (cm)
60 G- Next to vertical or horizontal pipe
H- Below the distance grille from the outside
60
of the building
I- Distance from the inner corner of the
30
building
30 L- From the ground or from the floor
40 M- Vertical distance of two flue outlets
60 N- Horizontal distance of two flue outlets
Table 3
POSITION
12
DISTANCE (cm)
60
30
100
180
150
100
