  • Page 1 ARCEUS ELECTRIC COMBI BOILER ARCEUS 6-9-12-15-18-24-27 kW MT / CH / ST USER AND INSTALLATION MANUAL...
  • Page 3: Table Of Contents

    CONTENTS INTRODUCTION ......................4 WARRANTY AND SERVICE ..................4 SYMBOLS ........................4 SAFETY RULES AND WARNINGS… ................5 Safety Rules ......................5 Installation ......................5 Assembly ......................5 Commissioning ....................5 Operation and Maintenance ................. 5 PRODUCT ........................6 General Specifications ..................6 Product Notation ....................
  • Page 4: Introduction

    1- INTRODUCTION First of all, thank you for choosing E.C.A. E.C.A. ARCEUS electric combi boilers are intended for meeting central heating and hot domestic water requirement in an efficient, safe, and comfortable manner. ARCEUS electric combi boilers can operate on 220-240 VAC (6/9/12 kW) and 380-415 VAC (6/9/12/15/18/24/27 kW) power. MT model: It is intended for both central heating and hot domestic water requirement.
  • Page 5: Safety Rules And Warnings

    These are descriptions containing information that should be taken INFORMATION intoconsideration by the user. CAUTION: Indicates that material damage or slight personal injury may occur. DANGER: Indicates that severe personal injury may occur. SAFETY RULES AND WARNINGS 4.1- Safety Rules The power line to which the device is connected must have cross-sectional dimensions as specified in the manual and grounded.
  • Page 6: Product

    CAUTION: This device is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge unless they have been given supervision or instruction concerning the use of the device by a person responsible for their safety. Children should be supervised to ensure that they do not play with the appliance.
  • Page 7: Product Notation

    5.2- Product Notation NOTATION DESCRIPTION ARCEUS 12-15-18-24-27 MT ARCEUS Monothermic Electric Combi Boiler ARCEUS 6-9-12-15-18-24-27 CH ARCEUS Central Heating Electric Combi Boiler ARCEUS 6-9-12-15-18-24-27 ST ARCEUS Central Boiler Aided Electric Combi Boiler Table 1. Device Notation Table...
  • Page 8: Wiring Diagrams

    5.3- Wiring Diagrams Circuit Breaker Contactor Electric Heaters Relay Board CH Flow NTC CH Return NTC Boiler Tank NTC 3 Way Valve DHW Solar STB Water Pressure Sensor DHW Outlet Sensor Modbus Communication Circulation Pump Figure 1. Arceus 6-9 kW Wiring Diagram...
  • Page 9 Circuit Breaker Contactor Electric Heaters Relay Boards CH Flow NTC CH Return NTC Boiler Tank NTC 3 Way Valve DHW Solar STB Water Pressure Sensor DHW Outlet Sensor Modbus Communication Circulation Pump Figure 2. Arceus 12-15 kW Wiring Diagram...
  • Page 10 Circuit Breaker Contactor Electric Heaters Relay Boards CH Flow NTC CH Return NTC Boiler Tank NTC 3 Way Valve DHW Solar STB Water Pressure Sensor DHW Outlet Sensor Modbus Communication Circulation Pump Figure 3. Arceus 18-24 kW Wiring Diagram...
  • Page 11 Circuit Breaker Contactor Contactor Electric Heaters Electric Heaters Relay Boards CH Flow NTC CH Return NTC Boiler Tank NTC 3 Way Valve DHW Solar STB Water Pressure Sensor DHW Outlet Sensor Modbus Communication Circulation Pump Figure 4. Arceus 27 kW Wiring Diagram...
  • Page 12: Detailed View, Component List And Installation

    5.4- Detailed View, Component List and Installation Figure 5. Component View of Device Air Purge 3 Bar Safety Valve Electric Heaters Circuit Breaker 10. Main Heat Exchanger Ground Terminal Block 11. Expansion Vessel Neutral Terminal Block 12. Drain Valve Neutral Busbar 13.
  • Page 13 Control Board Figure 6. Control Panel Elements Figure 6.1 Control Board Rear Cover and Terminal Connections...
  • Page 14 5.4.1- MT Model Installation DHW Outlet DHW Inlet CH Return CH Flow Figurel 7. Monothermic Device Installation Scheme 5.4.2- CH Model Installation CH Return CH Flow Figure 8. CH Device Installation Scheme...
  • Page 15: Packaging

    5.4.3- ST Model Installation CH Return Boiler Exit CH Exit Boiler Return Figure 9. ST Device Installation Scheme 6- PACKAGE CAUTION: Warnings on the carton package must be observed during transportation and storage of the device. - The device is delivered in a carton box with dimensions of 735 x 345 x 490 (HxWxD) as supported by lower and upper styrofoams.
  • Page 16: Wall Mounting Of The Device

    Upper side service space Min. 500 mm. Left and right side servicee space Min. 150 mm. Bottom side service space Min. 250 mm. Figure 10- Required spaces for the assembly of the device - The device can not be used at altitudes higher than 2000 m above sea level. - There is no need to remove side panels for the inside combi boiler service operations.
  • Page 17: Connections

    Figure 11. Bracket Assembly 8- CONNECTIONS 8.1- Water Pipe Connections - The water connections between the wall mounting bracket fixed on the wall and the combi boiler are made with the pipe group and nipples as shown in the figure 8.1.1- MT Model a) Central heating pipe 3/4"...
  • Page 18 8.1.2- HCH Model a)Central heating pipe 3/4" outlet line (hot) b)Central heating pipe 3/4" return line (cold) Figure 13. CH boiler water connections 8.1.3- HST Model a)Central heating pipe 3/4" outlet line (hot) b) Boiler outlet line 1/2" (hot) c) Boiler return line 1/2" (cold) d) Installation Filling line 1/2"...
  • Page 19: Electrical Connection

    8.2- Electrical Connection Your combi boiler must be connected to a grounded power line that can supply 230 VAC 50 Hz voltage for single-phase devices and 400 VAC 50 Hz voltage for 3-phase devices. Malfunctions caused by voltage fluctuations are not covered by the warranty.
  • Page 20 CAUTION: For single-phase operation, a power supply cord with suitable cross section defined for single- phase operation must be used. Figure 16. Bridging bar CAUTION: Bridging bar must not be used in 3-phase operation. CAUTION: Malfunctions caused by power supply grid are not associated with the device and are not covered by warranty.
  • Page 21: Room Thermostat

    8.3 Room Thermostat One of the optional room thermostats compatible with your device can be used to provide local heating control. E.C.A. On/Off Room E.C.A. On/Off Room E.C.A. Smart Combi Thermostat T6360 Thermostat T6360 Boiler Kit 7006901312 7006907804 7006907531 E.C.A. Digital Room Poly 100 W Room E.C.A.
  • Page 22: Initial Start-Up, Operation And Shut Down

    9- INITIAL START-UP, OPERATION AND SHUT DOWN 9.1- Initial Start-Up - First of all, the electrical connection of combi boiler should be made. The electrical connection of the device must be connected to a grounded supply line that can supply sufficient voltage for the device.
  • Page 23: Control Panel

    10- CONTROL PANEL 10.1- Button Functions Reset/Mode Selection Button Using mode can be changed pressing the mode selection button to change between the winter mode and the summer mode. If the button is pressed for 3 seconds, the device will switch to the "stand by"...
  • Page 24 Figure 18. Control Panel Button Configuration 10.2.1 Button Functions: Button Button Number Name Function - Increases central heating set temperature - Increases password value at parameter menu entry - Increases parameter value CH Plus - Indicates information value - Indicates error history value - Reduces central heating set temperature - Reduces password value at parameter menu entry CH Minus...
  • Page 25 - Reduces domestic water set temperature - Allows for selection between parameters, information, error history, and clear error history menus DHW Minus - Confirms the password at parameter menu entry - Reduces parameter number - Shows information number - Reduces fault history number - Allows for selection between STANDBY MODE, SUMMER MODE, and WINTER MODE when shortly pressed.
  • Page 26 10.3.5- Domestic Hot Water (DHW) Eco Mode: At the times that hot water demand is not expected (e.g. holidays etc.) or more economic use is preferred, ECO mode prevents the water in the exchanger to be heated and provides a more economic use of the device. When the ECO Mode is active “EC”...
  • Page 27: Error Codes And Descriptions

    10.4- Error Preventive Functions 10.4.1- Anti Freeze Protection: During the winter season, when the water temperature of the installation drops below 6⁰C, anti freze protection is activated and the device keeps on heating until water temperature reaches to 15⁰C. Below conditions must be provided and controlled by the customer for anti freze protection to work properly: - Power supply of the device must bu connected - Radiator valves must be open...
  • Page 28: Useful Product Information

    The water pressure parameter FP11 is at a low level. This error is displayed if the water pressure is less than FP11/10 Low Water Pressure bar. When the water pressure is greater than (FP11/10+0.4 bar), the error is automatically cleared. This error is displayed if the outdoor temperature sensor is short or Outdoor Temperature open circuit, or damaged.
  • Page 29: Disposal Of The Device

    If you use a program clock with your device, your combi boiler will run at the times you set and • consume less fuel. If you use your combi boiler with a room thermostat, it keeps the room temperature at •...
  • Page 30: Technical Data Table

    14.TECHNICAL DATA TABLE Device Type ARCEUS EK 6 ARCEUS EK 9 ARCEUS EK 12 ARCEUS EK 15 ARCEUS EK 18 ARCEUS EK 24 ARCEUS EK 27 Nominal Power (kW) Minimum Hea�ng Power (kW) 1~ 230 VAC 1~ 230 VAC 1~ 230 VAC Supply Power Voltage 3~ 400 VAC 3~ 400 VAC...
  • Page 31: Erp Manual

    15- ERP MANUAL 1- PRODUCT FICHES Product fiche for combination boilers as required by EU regulations No 811/2013 ARCEUS Combi ERP Units MT Model Supplier's name or trademark E.C.A. Arceus 12 Arceus 15 Arceus 18 Arceus 24 Arceus 27 Supplier's model identifier Space Heating-Temperature application Medium Seasonal Space...
  • Page 35 SELLER COMPANY'S Invoice Date and No: Title : ................................... Address ................................... Submit Date and Location: ..................................Tel - Fax : ..................Date, Signature and Seal: ..................PRODUCT'S Type : Electric Boiler Serial Number ................Brand : E.C.A. Submit Date and Location: ................
  • Page 36 PRODUCTION Organize Sanayi Bolgesi 3.Kisim Mustafa Kemal Boulevard No:13 45030 MANISA Tel.:+90 236 213 00 21 Fax:+90 236 213 08 59 email:emas@emas.com.tr www.emas.com.tr...
