You can mount the Studio X72 above or below a display. The Studio X72 doesn't support inverted
mounting. For information on mounting the Studio X72, see the Studio X72 setup sheet.
Poly Studio X72 Hardware
•
Poly Studio X72 Privacy Shutter Behavior
The privacy shutter automatically opens and closes depending on the state of the connected
video system.
•
Poly Studio X72 System Hardware Ports
The following illustration and table explain the hardware ports on your Poly Studio X72 system.
Table 1.
Ref. Number
1
2
3
4
Printed from Poly (http://docs.poly.com)
Feature
Screen
Microphone array
Speakers
Dual cameras
Description
Protective screen that covers
the front of the system
Microphone array that captures
audio
Stereo audio output
Camera array with a privacy
shutter that automatically
opens or closes, depending on
the camera state
