Scanner Operation Panel
The scanner operation panel is located on the front right side of the scanner, includes nine physical
buttons and an LCD screen. Through this panel, you can directly configure the settings for scanner's
hardware functions without having to connect to a computer. These functions include counting
pages, checking scan and roller counts, setting the idle time before sleep mode activates, and more,
providing you with a convenient and practical hardware interface.
Press to enter Function
mode from Ready mode.
It also serves as a
confirmation button for a
selection.
PREV ( ):
Press to go back to the
previous option.
COUNT:
Press to enter Count mode;
press again to return to
Ready mode.
Press to pause the ongoing
page counting or scanning
operation.
The scanner operates in three main modes: Ready, Function, and Count. For detailed instructions on
how to access and use each mode, please refer to the scanner's user manual, which is available on
the Microtek website.

Troubleshooting

If you encounter issues while using the scanner, please first refer to the "Troubleshooting" section
of the scanner's user manual available on the Microtek website for common problems, and follow
the recommended steps for a possible solution. If the issue still remains, please contact the Microtek
Customer Service Departement for further assistance.
TASK:
STOP:
LCD panel:
Displays information relevant
to the current operation mode
or task in progress, as well as
any error messages that may
occur.
RESET:
Press to reset the page or scan
count to zero.
NEXT ( ):
Press to move to the next
option.
DBL:
Press to enable/disable the
scanner's ultrasonic double
sheet detection function.
START:
Press to begin the page
counting process.
