Basic Scanning

1. Load the documents to be scanned into the scanner's feed tray.
2. Launch "Microtek DocWizard EX" software by double-clicking its program icon on the
desktop.
3. Go to "Scan > Select device source". Select the scanner driver "Microtek A3FZ
Scanner" from the window that appears, and then click OK.
Once the scanner is found, the status bar will show the message "Device Microtek A3FZ
Scanner is open", indicating that the scanner is prepared for scanning.
4. Select "Scan > Scan settings" and configure the necessary scan settings in the window (TWAIN
interface) that appears for your scan job.
For details on how to configure the scan settings, refer to the online help manual by clicking on
the "Help" button in the window.
5. Once completed, select "Scan > Scan" to start scanning.
After scanning is complete, the scanned images will be automatically saved to the system's
default folder and displayed as thumbnails in the Thumbnail area and Preview area for viewing.
6. Select "File > Export..." to save the scanned images with the file properties you specified in the
Export dialog box.
Thumbnail
area
Status bar
NOTE: For detailed information on using the DocWizard EX scanning software, please refer to the
online help manual included with the software.
4
Preview
area
