The
CV
constant voltage mode
The
CC
constant current mode
The power supply is in high
*
voltage range
Meter
"Meter" key is pressed
Shift key is pressed, use
Shift
compound keys
OVP
OVP function is enabled
OCP
Not in use

2.5 Rear Panel Introduction

The rear panels of IT6800A/B series power supply are divided into series-A and
series-B.
The rear panels and keyboards of IT6800A series power supply are shown as
below.
①
Cooling window
③
USB communication interface
⑤
AC
The rear panels and keyboards of IT6800B series power supply are shown as
below.
power supply is
power supply is
(fuse contained)
power socket
Copyright © Itech Electronic Co., Ltd.
www.tehencom.com
in
Sense
Not in use
in
Ext
Not in use
(USB) light when the
Adrs
address match or (RS232)
received order
The power supply is in
Rmt
remote mode
The power supply has
Error
error or fault
The power supply is in
Prot
OVP /OTP protection
Lock
Keypad is locked
②
Remote sense terminal
④
RS232 communication interface
Quick Start
9
