to confirm
VFD displays LIST STATE, press
3.
LIST>OFF, press
Enter
Then button will be lit. You have enables list mode.
to select LIST EDIT, press
4. Press
VFD displays TIME SEC, press
5.
to select >TIME MIN. Press
or press
matter you select SEC or MIN,the adjustable range is 0.1~9999.9
VFD displays VSET 0.000, press numeric keys
6.
rotary knob to set voltage, press
VFD displays ISET 0.0000, press numeric keys
7.
rotary knob to set current, press
VFD displays SEC 0.1, press numeric keys
8.
knobs to set time press
VFD displays NEXT >YES, press
9.
10. Repeat steps from 5）~8) for four times. The last time, when VFD shows
NEXT >YES, press
11. VFD displays REPET 1, press numeric keys
knob to set cycle counts, press
range:1~65535.
12. VFD displays SAVE >NO, press
current list file does not be saved. It can only run once. As long as you quit
the list mode or turn off the unit, the list file will not exist anymore.You also
to select >SAVE FILE0 to save the file into assigned
can press
memory location for quick recall. Press
13. If you intends not save the list file, VFD will directly display LIST EDIT.If you
select to save the list file, VFD will display LIST EDIT after blinking
contents of SAVE DONE for about three seconds.
Esc
14. Press two times to exit menu operation.
15. After you edit a list file, set the trigger source in the menu to "MANUAL"
On/Off
16. Press button to turn on the output. Press
(Trigger) to generate a trigger signal to execute a list file.
17. If you have saved multiple list files. LIST LOAD item can help you to recall
assigned file that you need. Then press
operation. Then the same operation as step 16）
18. Press (Shift)+
LIST SET, press
Enter
to confirm-------press
confirm.
