Chapter1 Inspection and Installation

1.1 Verifying the Shipment

Unpack the box and check the contents before operating the instrument. If
wrong items have been delivered, if items are missing, or if there is a defect
with the appearance of the items, contact the dealer from which you purchased
the instrument immediately. The package contents include:
Checklist of Package Contents
Item
Power Supply
Power cord
Ex-factory Test
Report

1.2 Instrument Size Introduction

The instrument should be installed at well-ventilated and rational-sized space.
Please select appropriate space for installation based on the power supply size.
IT6800A/B
of the
Detailed Dimension Drawing
Qty.
x1
x1
x1
NOTE
Upon verification of the shipment, keep the package and relevant contents thereof in a
safe place. When returning the instrument for warranty service or repair, the specified
packing requirements shall be met.
series
power supply
are shown as below. (Take the example of IT6862A)
power supply
Copyright © Itech Electronic Co., Ltd.
www.tehencom.com
Model Remarks
The IT6800A/B series include:
IT6831A/IT6832A/IT6833A/IT683
5A/IT6861A/IT6862A/IT6863A/IT6
IT6800A/B
872A/IT6873A/IT6874A/IT6832B/I
Series
T6833B/IT6835B/IT6861B/IT6862
B/IT6863B/IT6872B/IT6873B/IT68
74B
User may select an appropriate
power cord that matches the
IT-E171/IT-E172
specifications of power socket
/IT-E173/IT-E17
used in the area. See the
4
Section Connecting the Power
Cord for details.
It is the test report of the
-
instrument before delivery.
different models are the same size, the detail size
Dimension:
Width: 255.3mm
Height: 108.7mm
Depth: 374.4mm
Inspection and Installation
1
