3.8 Save/Recall

IT6800A/B series power supply enables customer to store up to 9*8 groups of
different operating parameters in a non-volatile memory. You can save or recall
parameters by
through command *SAV,*RCL.
Each operating parameters includes a constant voltage value, constant current
value and OVP setting value.
Save operation:
Set the desired Voltage and Current value
Press the
Press
Recall operation:
Keep group setting unchanged, press
memory location where the settings you want to recall are stored.
Group Concept:
When storage amount exceeds 9, you have to enter into menu and select MEM
item to change the group set. Meanwhile, to recall a pre-stored parameter
should be coordinated with correct group set. For example, if you want to recall
parameters which are stored in memory location from 10 to 19, then MEM
should be set to group 1.
To change group set:
Press
select SYST SET, press
Press

3.9 Trigger operation

IT6800A/B series power supply supports two different trigger modes Manual
and Bus. Configure one of the trigger sources before performing trigger
operation.
This operation is often used with list operation. It provides a trigger signal to
start running a list file. During the process of running a list file, trigger button
Enter

3.10 Menu Operation

Press
knob to scroll through the menu list and press
view the parameters. Press Esc button to return to the higher level menu and to
quit the menu setting.
IT6800A series
MAX
Set the Maximum Voltage
VOLT
P-MEM
SYST
(RESET)
Recall
(Shift) +
Recall
(Shift) +
Enter
to confirm.
I-set I-set
(Shift) + button to enter the menu, press
Enter
to select MEM, enter a numerical value, press
(Trigger) will keep blinking until finished.
I-set I-set
(Shift) + (Menu) to enter menu mode. Use the
Reset
Return to the factory default setup value
Keep
"Remembers" and restores the operating
Copyright © Itech Electronic Co., Ltd.
www.tehencom.com
(Save)buttons directly from the front panel or
+number 1 to 9 to assign a memory location.
Recall
+number 1 to 9 to select the
to confirm.
Enter
Functions and Characteristics
button to
Enter
to confirm.
, or
to select a item and
16
