RANGE HOOD USE
Range Hood Control Panel
Hand Delayed
Gesture
Auto
Control
Shut Off Light
HAND GESTURE CONTROL
• To Enable/Disable Hand Gesture Control:
• Touch the Power button once to turn on
the hood.
Touch the Hand Gesture Control button
•
once to enable/disable the function to
control the hood with hand gestures.
• Controling The Hood With Hand Gestures:
Note
The Hand Gesture Control function must
be enabled first.
• Swiping from right to left
• Swipe once to turn on the hood at
the lowest speed F1 and turn on
the LED lights.
Swipe again will increase the speed
•
to F2. Each following consecutive
swipe will increase the speed level
by 1 until the highest speed is
reached.
• Swiping from left to right
• Swipe once will activate the
Delayed Auto Shut Off function.
(Default countdown timer is 3
minutes, which can be adjusted
with the Speed (-) or Speed (+)
button.)
• Swipe twice continuously will shut
off the hood and the LED lights
immediately.
REMOTE CONTROL SENSOR
• The remote control sensor receives infrared (IR)
signal from the remote control.
• The maximum distance for IR data
transmission is 10 feet and requires direct line
of sight.
• The transmission distance may vary
depending on the room temperature and the
condition of the battery in the remote control.
Hand
Gesture
Censor
Speed Power
DELAYED AUTO SHUT-OFF
• When the hood is operating in any speed, touch
the this button once will activate the Delayed
Auto Shut Off function.
Touch the Speed (-) or Speed (+) button to adjust
•
the duration of the countdown timer.
• The timer can be adjusted between 1 minute
to15 minutes using the Speed (-) or Speed (+)
button. (1 minute by default.)
The Delayed Auto Shut Off Indicator will be
•
illuminated in the LCD Display once the timer
is set and counting.
• The timer will start immediately once it's set.
When it reaches 0, the Range Hood and the
Light will be turned off automatically.
CLOCK / CURRENT TIME DISPLAY
When the Delayed Auto Shut Off function is
•
not activated, the LCD Display will show the
current time of the day.
THE CLOCK CAN ONLY BE SET WHILE THE
BLOWER IS OFF.
• To set the Clock:
Touch the Delayed Auto Shut Off button
•
once. The hour indicator will flash.
Touch the Speed (-) or Speed (+)button to
•
adjust to the desired hours.
• When done setting the hour, touch the
Delayed Auto Shut Off button again. The
minute indicator will flash.
Touch the Speed (-) or Speed (+) button to
•
adjust to the desired minutes.
• When done setting the minutes, touch the
Delayed Auto Shut Off button to confirm
all settings.
Touch the Light button to check and
•
validate the time.
• When the Delayed Auto Shut Off fuction is
activated while the blower is running, a
countdown timer will show up in the LCD
Display.
LIGHT
Touch the Light button once and the lamps will
•
turn on.
Touch the Light button again and the lamps will
•
turn off.
• The Light button operates independently from
the Power button. It works even when the
range hood is not turned on.
• Always turn off the lamps before powering off
the range hood.
