PSMB068P110
Preparing for operation
ATTENTION! Unpacking and installation of the interactive panel should be performed by qualified installers (at least two people).
1. Carefully open the box, take out the device and accessories. Remove any packaging materials.
2. Make sure that the location selected for installation can support the weight of the device, and that there is sufficient air circulation
around.
3. Install the interactive panel in vertical position (without tilting) using one of the recommended methods (III, IV).
4. Make sure that all screws are tightened securely. To reduce glare, position the interactive panel so that direct light does not shine
on its screen.
5. Determine which devices to connect to the interactive panel connectors (I).
Connector
AUDIO IN
Audio signal input from an external device (media player, smartphone, etc.)
AUDIO OUT Audio signal output to an external device (acoustic systems, headphones, etc.)
DP IN
High-definition digital audio and video signal input (up to 3,840×2,160 pixels, 30 Hz) from an external computer
HDMI IN
High-definition digital audio and video signal input (up to 3,840×2,160 pixels, 60 Hz) from an external device
(computer, TV decoder, etc.)
HDMI OUT
High-definition digital audio and video signal output (up to 3,840×2,160 pixels, 60 Hz) to an external device (computer,
external monitor, etc.)
JAE (80 pin)
Data exchange with the built-in mini computer (compatible mini computers: PMB528K001, PMB528K002,
PMB528K003, PSMB528K001)
LAN (RJ45)
Data exchange with network devices (router, etc.)
MIC IN
Audio signal input from an external microphone
RS232 IN
Control signal input from an external computer
S/PDIF
Digital audio signal output to external acoustic systems with S/PDIF connector
USB Type A
Data exchange with peripheral devices (keyboard, mouse, flash drive, etc.), powering/charging devices (up to 5.25 V,
0.9 A)
USB Type B
Data exchange with peripheral devices (external computer, external hard drive, etc.), powering/charging devices (up
to 5.0 V, 0.5 A)
USB Type C
Data exchange with peripheral devices (keyboard, mouse, flash drive, etc.), powering/charging devices (up to 20.0 V,
3.0 A)
VGA IN
Analog video signal input (up to 1,920×1,080 pixels, 60 Hz) from an external computer
ATTENTION! Connect external devices only when the interactive panel is turned off.
NOTE. Peripheral devices and mini computer are not included in the package. Signal quality and charging speed depend on the cable
characteristics, so use original certified cables.
6. Connect the power cable to the interactive panel. Insert the plug into the mains socket.
ATTENTION! The power cable must be plugged into the mains socket without strain.
7. Turn the power toggle switch (I-29) to position I ("On"). Wait for the OS Android interface to appear on the screen.
8. Control the interactive panel with (choice of):
Touch screen;
Remote control;
Keyboard and mouse;
External computer and its controls.
NOTE. When using the remote control, make sure there are no obstacles (obstructions, foreign objects) to the IR signal.
Power button indication
Indicator status
On (blue)
The device is turned on and operating
On (red)
The device is in standby mode
Flashing red and blue
The device firmware update is in progress
Off
The device power is off (the device is not operating)
9. If necessary, select a signal source. Press the button (II-3) on the RC unit or enter the Sidebar Menu on the screen (tap the button
or at the right or left edge of the screen, respectively, in the menu that appears, tap the button
signal sources.
10. Set up access to the Wi-Fi network. In the Sidebar Menu, tap the button
In the list that appears, select the desired network, then tap "Connect". The interactive panel can also be used as a Wi-Fi hotspot for
nearby devices. To do this, from the "Network Settings" tab, select the "Hotspot" option and activate the function using the switch on
the screen.
11. To connect wireless devices (keyboard, mouse, speakerphone, etc.) via BT, select the "BT" option in the "Network Settings" tab
and activate BT using the switch on the screen. Select the required device from the list and pair it (see also the peripheral device
instructions).
© 2024 Prestigio Solutions
Intended use
Description
("System Settings"), select the "Network Settings" tab.
). Select one of the available
9
