I – Appearance (see pages 4–5)
A – front panel
1 Video camera
2 Screen
3 USB Type C connector
4 HDMI IN connector
5 USB Type B 3.0 connector
6 USB Type A 3.0 connectors
7 Microphones
8 NFC sensor
9 IR receiver, light sensor
10 Power button
11 Handles
12 Slot for mini computer (
13 Power connector
14 USB Type B 3.0 connectors
15 DP IN connector
NOTE. The I-9 elements are combined into one unit and concealed by non-removable protective cover.
II – Remote control unit (see page 5)
A – appearance
1 Power button
2 Source selection button
3 Menu navigation buttons
4 Confirmation button
5 Button to enter / exit System Settings menu
6 Button to open the home page of the menu
NOTE. The remote control requires 2 AAA batteries (not included in the package).
III – Wall mounting example (see page 6)
ATTENTION! A VESA standard wall mount is required. Installation involves drilling into the wall. Installation tools (drill,
hammer, screwdriver, wrench, construction level) are required. They are not included in the package.
1 Installing vertical guides on the interactive panel
2 Installing the interactive panel: aligning the guides and the mounting frame
3 Additional fixation
NOTE. See also the instructions for the wall mount used.
NOTE. The wall mount is not included in the package.
IV – Example of installation on a floor stand (see page 6 *)
ATTENTION! If you are using a stand on wheels, you must lock the wheels before installing the interactive panel on it.
NOTE. See also the instructions for the floor stand used.
NOTE. The floor stand is not included in the package.
* Stand type may vary.
© 2024 Prestigio Solutions
B – side panels
JAE connector)
B – recommendations for use
C – bottom panel
16 HDMI IN connectors
17 USB Type C connector
18 USB Type A 3.0 connectors
19 USB Type A 2.0 connector
20 SD card slot
21 S/PDIF connector
22 AUDIO OUT connector
23 HDMI OUT connector
24 MIC IN connector
25 RS232 IN connector
26 LAN (RJ45) connectors
27 VGA IN connector
28 AUDIO IN connector
29 Power toggle switch
7 Button to return to the previous page of the menu
8 Button to switch to mini computer
9 Button to call the writing and drawing function
10 Screenshot button
11 Volume control buttons
12 Mute/unmute button
