1.6 Appearance and Illustration
1. LCD Screen
2. NMS Port
3. DATA Port
4. Power and Alarm Indicators
5. Lock 1 and Lock 2: SDI input locking status; Lock 3: ASI in locking status. Lock 4: useless
Up and Down, Left and Right Buttons
6.
7. Enter Button: for confirm
8. Menu Button: for back step
9. Lock Button: To Lock the screen / cancel the lock state
1
1. SDI Input interface
2. RF in for mix
3. RF Output interface
4. ASI in for mux
5. ASI out
6. Power Switch
7. Power Socket
8. Grounding
