H-HDMI-RF-PETIT-IR
Step 1: Connect and Login
Connect IR Sensor
to "IR OUT"
Solid "STATUS"
LED indicates
that input is
properly
connected.
Blinking means
not connected.
TO CONSOLE WITH PC:
Connect the NMS port to your PC using an ethernet cable
Open web browser and go to http://192.168.0.188
Login/Password: admin/admin
https://thorbroadcast.com
RF
RF
RF
OUT
OUT
IN
If using the IR Return option, set
the 9V Switch to "ON". Blue LED
will indicate proper connection
800-521-8467
Connect Included Power Supply
NMS
HDMI
HDMI
OUT
IN
Red LED on
sensor also
indicates
proper
conection
Connect to
"RF OUT"
sales@thorfiber.com
Quick Setup Guide
Connect
to TV
"PWR" LED
indicates that
power is properly
connected
