- Page 1 H-HDMI-RF-Petit-IR A Note from Thor Broadcast about this Manual Intended Audience User Manual This user manual has been written to help people who have to use, integrate and to install the product. Some chapters require some prerequisite knowledge in electronics and especially in broadcast technologies and standards.
-
Page 2: Table Of Contents
H-HDMI-RF-Petit-IR H-HDMI-RF-Petit-IR Table of Contents Chapter 1 - Introduction CHAPTER 1 – INTRODUCTION 1.1 Product Overview H-HDMI-RF-Petit-IR modulator has an HDMI input with local loop through, and a COFDM PRODUCT OVERVIEW output which is combined with the RF input. The HDMI input content can be supplied by a number of KEY FEATURES sources, Blu-ray player, Satellite Set top box, CCTV etc. -
Page 3: Specifications
H-HDMI-RF-Petit-IR H-HDMI-RF-Petit-R 1.3 Specifications 1.4 Appearance and Description Encoding Section-Video Encoding MPEG2/H.264 Interface HDMI*2(1×input/1×loop through) Panel Illustration Input Output Resolution 720@50p,720@60p Max.1080@30p 1080@50i/p,1080@60i/p 5-25Mbps Bit rate Encoding Section-Audio Encoding MPEG-1 Layer2, AAC, AC3 Sample rate 48KHz System Management LCD + Control buttons/Ethernet... -
Page 4: Application Drawing
H-HDMI-RF-Petit-IR H-HDMI-RF-Petit-IR 1.5 Application Drawing Chapter 2 - Operation Keyboard Function Description: Version 1.04 ENTER: Activate the parameters which need modifications, or confirm the change after modification. 6. Network, 00000203 System ESC: Cancel current entered value, resume previous setting; Return to previous menu. - Page 5 H-HDMI-RF-Petit-IR H-HDMI-RF-Petit-IR Program Number Encode Input source Program Provider TF HD1 HDMI Bit Rate 19.000Mbps Program Name TF HD1 Latency 500/800/1000 Audio Format AC3/AAC/Mpeg1 layer2 Network ID PMT PID Video PID Audio PID Encode PCR PID Input source HDMI Bit Rate 19.000Mbps...
-
Page 6: Installation Operation
H-HDMI-RF-Petit-IR H-HDMI-RF-Petit-IR Chapter 3 - WEB NMS Operation 2.2 Installation Operation For setting configurations you can use the front panel; also you are able to control and set the configurations on any computer by connecting the device to the web NMS Port. You should ensure that the computer’s... -
Page 7: Operation
H-HDMI-RF-Petit-IR H-HDMI-RF-Petit-IR 3.2 Operation Summary When we confirm the login, it displays the Summary interface as shown in Figure-2. DVB-C(J.83A) Modulation Parameters → Encode: Click [ Encode ], it displays the information of the program from the HDMI encoded channels, users... - Page 8 H-HDMI-RF-Petit-IR H-HDMI-RF-Petit-IR DVB-T Modulation J.83B Modulation DVB-C(J.83A) Modulation ISDB-T Modulation ATSC Modulation System → Modulate: Click [ Modulate ], it displays the interface where users can configure the modulating parameters. Tel: (800) 521-8467 Email: sales@thorfiber.com http://www.thorbroadcast.com Tel: (800) 521-8467 Email: sales@thorfiber.com...
- Page 9 H-HDMI-RF-Petit-IR H-HDMI-RF-Petit-IR System→Password: Click [ Password ], it displays the screen where to set login password for the web NMS J.83B Modulation System→Firmware: Click [ Firmware ], it displays the screen where to update the firmware on this modulator. ISDB-T Modulation System →...
- Page 10 H-HDMI-RF-Petit-IR H-HDMI-RF-Petit-IR System → Configuration: Click [ Update Modulator Firmware ] to put file up then auto start update. Progress shown below. Click [ Factory Set ], it displays the screen Click OK to Factory default Setting. Click [ Load Configuration ], it will jump a windows to upload the file that saved settings before.
-
Page 11: Chapter 4 - Packing List
H-HDMI-RF-Petit-IR Chapter 4 - Packing List BROADCAST H-HDMI-RF-Petit-IR User's Manual HDMI Cable Power adaptor IR emitter IR receiving eye For Further Tech Support 1-800-521-Thor(8467) support@thorfiber.com Tel: (800) 521-8467 Email: sales@thorfiber.com http://www.thorbroadcast.com...
