1.3 Technical Specifications
HDMI Encoder Board
SDI Encoder Board
Tel: (800) 521-8467
Input
Encoding
Bitrate
Resolution
Video
Support object
resolution
(for downscale
conversion)
Low Delay
Chroma
Aspect Ratio
Encoding
Dialog
Normalization
Audio
Applicable for DD
AC3 encoding only)
Sample rate
Bitrate
Encoding
Input
Bitrate
Resolution
Video
Support object
resolution
(for downscale
conversion)
Low Delay
Chroma
Aspect Ratio
Encoding
Dialog
Normalization
Audio
Applicable for DD
AC3 encoding only)
Sample rate
Bitrate
Email: sales@thorfiber.com
H-1/2/4SDI-QAM-IPLL
HDMI*2
MPEG2; MPEG4 AVC/H.264
1-19.5Mbps
1920*1080_60P, 1920*1080_50P,
(-for MPEG4 AVC/H.264 only)
1920*1080_60i, 1920*1080_50i,
1280*720_60p, 1280*720_50P
720*480_60i, 720*576_50i
1920*1080_60i, 1920*1080_50i,
1440*1080_60i, 1440*1080_50i,
1280*720_60p, 1280*720_50P
720*480_60i, 720*576_50i
Normal, Mode 1, Mode 2, Manual
4:2:0
16:9,4:3
MPEG1 Layer II;MPEG 2-AAC; MPEG 4-
AAC and Dolby Digital AC3 2.0(optional)
-31 ~ -1 dB
48KHz
64/96/128/ 192/256/320kbps
MPEG2; MPEG4 AVC/H.264
SDI*2
1-19.5Mbps
1920*1080_60P, 1920*1080_50P,
(-for MPEG4 AVC/H.264 only)
1920*1080_60i, 1920*1080_50i,
1280*720_60p, 1280*720_50P
720*480_60i, 720*576_50i
1920*1080_60i, 1920*1080_50i,
1440*1080_60i, 1440*1080_50i,
1280*720_60p, 1280*720_50P
720*480_60i, 720*576_50i
Normal, Mode 1, Mode 2, Manual
4:2:0
16:9,4:3
MPEG1 Layer II ,MPEG2-AAC, MPEG4-AAC
and Dolby Digital AC3 2.0(optional)
-31 ~ -1 dB
48KHz
64/96/128/ 192/256/320kbps
