JLL IC 400 PRO Instruction Manual page 6

NO.
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77 The brake connection assembly
78
79
80
81 The brake block assembly
82
83
84
85 The left front magnetic control brake decora-
86 The right front magnetic control brake decora-
87
88
NAME
Little chain cover
Axis
Long fixing tube
Short fixing tube
Inner chain cover
Belt
Belt wheel
Washer 2
Spring 1
Screw rod
Washer 2
Wheel
Flat washer
Fixing nut 2
Fixing tube
Bearing
Flywheel
Flywheel shaft
Fixing tube
Computer
Bolt 3
Nut
Flywheel cover
Left protective cover
Right protective cover
Pulse
Screw 5
Sensor
Screw 4
Spring washer 1
Bolt 1
Brake spring
The trachea
Bolt 6
Bolt 7
High magnetic
The brake guide sleeve
Corrugated casing
tion cover
tion cover
Plastic ring
End cap 1
QTY SPEC
1 108x37x3 (7g)
1 20x162
1 25x20.2x41.2
1 25x20.5x10.5
1 451x260x2 (250g)
1 5PK52
1 200x24
1 20x14x2
3 18x70
1 13.5x145
1
1 50x23
2 GB/T 95-2002 12
2 M12x1.25 H=6
2 16x12.1x35
1 6001ZZ
2 453x27(22kg)
1 12x160
1 16x12.2x56.1
1 SI-8210
1 GB/T 5780-2000 M5x10
4 M20x1.0
1 59x35
1 209x164x88
1 209x164x83
1
2 GB/845-85 ST4.2x25
2 SR-202
1 GB/845-85 ST4.8x13
2 GB/T 859-1987 5
2 GB/T77-2007 M6x6
1
1 18x18x1.2
1 7.5x6x28
1 GB/T 70.1-2000 M6x35
2 GB/T 70.1-2000 M6x12
1 WELDING
5 28x20x3
1 18x18x1.2
1 60x42x90
1 192x30x51
1 192x36x51
2 20x9x3
3 14x14
M10
2x15
