- Page 1 INSTRUCTION GUIDE IC400 PRO MONITOR...
- Page 2 The contents of this manual are subject to change without notice to improve quality. © 2023 JLL Fitness Ltd JLL Fitness Ltd owns the copyright for this manual. Use or reproduction of this manual in parts or entirety without the authorization of JLL Fitness Ltd is prohibited.
-
Page 3: Table Of Contents
CONTENTS - Safety precautions p. 4 - Cleaning p. 5 - Installation p. 6 - Operation p. 7 p. 7 Creating users p. 8 Setting target programs p. 8 Watt program p. 9 Heart rate band p. 9 Bluetooth/iConsole app p. -
Page 4: Safety Precautions
SAFETY PRECAUTIONS The monitor on this machine has been tested to the required standards, each of those passed regulations are shown via the following symbols: WEEE - Waste Electrical and Electronic Equipment Recycling. ABS - Acrylonitrile Butadiene Styrene often referred to as ABS is a type of plastic that is an opaque thermoplastic. CE - The product conforms with relevant EU directives regarding health and safety or environmental protection. -
Page 5: Cleaning
CLEANING Please take care when cleaning this monitor as the LCD screen can easily be scratched. You will need a soft dry cloth Do not spray cleaning chemicals directly onto the monitor Do not apply water to the monitor as it is electrical and may damage the internal components... -
Page 6: Installation
INSTALLATION STEP 1 STEP 2 Insert the batteries, making sure they are the Remove the four screws already in the back of correct way round. the monitor. STEP 3 STEP 4 Connect the male to female wires from the Secure the monitor to the frame using the four vertical post to the monitor. -
Page 7: Operation
Please be aware, if there 4 minutes of no activity the monitor will power off. CREATING USERS The IC400 Pro monitor allows you to input up to 4 different users. • When the monitor is powered on, you will be able to select a user from 1-4 using the silver dial. -
Page 8: Setting Target Programs
SETTING TARGET PROGRAMS After entering the user data settings use the dial to select the workout mode. You can set a target time, distance, calories, heart rate and wattage. • Once you have input the weight of the user or selected ‘NO’ when asked to edit a user the monitor will then show only the Time digits. -
Page 9: Heart Rate Band
HEART RATE BAND The heart rate band must be placed tightly around your chest with the sensor having skin contact consistently throughout any workout. Align the sensor approximately with your diaphram. There is no on/ off switch, the band will connect automatically to the monitor once a pulse signal is read. -
Page 10: Data Readouts
DATA READOUTS Readout Measurement Time Minutes : Seconds Speed Distance Miles Pulse PPM (Pulsations Per Minute) Revolutions Per Minute... -
Page 11: Troubleshoot
TROUBLESHOOT Issue Resolutions No power to the monitor • Make sure the batteries are fully inserted and the correct way round. • Check your connection wires from the monitor to the vertical post. They must not be trapped, fully connected and the pins must be straight. -
Page 12: Contact Details
CONTACT DETAILS Tel: 0121 328 7507 Email: info@jllfitness.co.uk Live Chat: WWW.JLLFITNESS.CO.UK... - Page 14 @JLLFITNESS...
