• redfish message interface
• IPMI event log and alerting
– event logs reading
– sensor readings (5 VSB, 12 V, RTC and thermal sensors)
– LAN
• Web-based configuration
– full configuration using GUI
– fail-safe BMC firmware upgrade
• SSH-based Serial Over LAN (SoL)
– power control of the server
– complete command support
– firmware update
– role-based authentication and authorization
• system inventory data via IPMI FRU
• system fan control
• remote BIOS update of the SPI flash on the carrier board
6.2 IPMB Header
The conga-HPC/uATX-Server provides IPMB signals on pin header JP6.
Table 47 JP6 - IPMB Header
Pin Description
1 IPMB_CLK
2 IPMB_DAT
3 GND
Copyright © 2024 congatec GmbH
1
HATXm001
JP6
1
2
3
