BMC
Power Management
Software
Other Features
Note
1. M.2 key B supports PCIe Gen 3 x2, 1x USB 2.0 and nano SIM slot instead with a custom variant (BOM option)
2. The 1 GbE port X19B supports only BMC management (without network connectivity)
3.2 Mechanical Dimensions
The conga-HPC/uATX-Server has the following dimensions:
• lenght of 243.84 ± 0.1 mm
• width of 243.84 ± 0.1 mm
• height of 30.57 ± 0.1 mm mm (25.27mm top-side, 2.00 mm PCB and 3.30 mm bottom-side)
3.3 Supply Voltage Power
The conga-HPC/uATX-Server supports 12 V DC ± 5 %.
Copyright © 2024 congatec GmbH
Aspeed AST2600
ACPI 6.0
AMI Megarc SPX BMC firmware
ASPEED Video BIOS
Thermal and voltage monitoring
CMOS Battery
Boot from external BIOS flash
