3 Specifications
3.1 Feature List
Table 5 Feature Summary
Form Factor
Supported Modules
Onboard Connectors
and Features
External IO
Copyright © 2024 congatec GmbH
Standard Micro-ATX
congatec COM-HPC size D server modules
1x PCIe Gen4 x16
1x PCIe Gen4 x8 (with open slot to support x16 PCIe cards)
1x M.2 Key B 2242/3042/3052/2280 (1x USB 3.0, 1x USB 2.0, PCIe Gen 3 x1 and nano SIM slot by default )
2x M.2 Key M 2230/2242/2280/22110 (PCIe x4)
1x BMC UART (RS232/RS422/RS485)
1x UART for BMC management
1x IPMB header (JP6)
2x SATA
1x GPIO header
1x General Purpose SPI header
1x USB 2.0 header (USB ports 4 and 5)
1x SMBus header
1x I2C0 header
1x I2C1 header
4x System fan (via the BMC)
1x SPI boot flash socket
1x Test header
1x ATX 24-pin power connector
1x EPS 8-pin power connector
1x RTC CMOS battery holder
1x Nano SIM card
1x External power button header (X44)
1x External reset button header (X46)
1x Runtime power LED header (X47)
1x S3 state LED header (X49)
1x Power button (SW9)
1x Reset button (SW10)
1x COM-HPC type detection header (2-pin)
4x SFP28/SFP+ cages for various transceiver technologies
1x 1 GbE RJ45 (BMC Management)
2
3x 2.5 GbE RJ45 with IEEE1588 support
1x DisplayPort (BMC)
3x USB 3.1 Gen1 (Type A)
1x USB 3.1 Gen1 (Type C)
