4.7 SATA
The conga-HPC/uATX-Server provides two standard SATA connectors:
• SATA port 0 on connector X21
• SATA port 1 on connector X22
The ports are routed via a dual-channel linear redriver.
Connector Type
X21, X22: Standard SATA plug
4.8 System Fan Headers
The conga-HPC/uATX-Server provides four 4-pin system fan headers (X27 - X30) via the BMC. The BMC controls the speed of the fans. The
system fans comply with the 4-wire Pulse Width Modulation (PWM) Controlled Fans Specification 1.3.
Use the following jumpers to set the supply voltage for the system fans:
• JP2 for pin header X27 (system fan 1)
• JP4 for pin header X29 (system fan 2)
• JP3 for pin header X28 (system fan 3)
• JP5 for pin header X30 (system fan 4)
With the default BMC firmware, the system fans:
• X27 and X28 operate at the same speed. However, only X27 supports RPM monitoring (TACHOIN).
• X29 and X30 operate at the same speed. However, only X29 supports RPM monitoring (TACHOIN).
Note
1. For independent speed control, you need a modified congatec BMC firmware. For more information, contact your local sales representative.
2. System fans 3 and 4 (X28, X30) do not support RPM monitoring with the default BMC firmware.
Copyright © 2024 congatec GmbH
X21
7 6 5 4 3
1, 2
1, 2
HATXm001
X22
Port 1
Port 0
7 6 5 4 3 2 1
2 1
