(8) Disable NCW-3DHIP requests to BOOTP/DHCP server
Choose NCW-3DHIP in the "Relation List" field, and click "Disable BOOTP/DHCP".
Then, a message of "[Disable DHCP] Command successful" is displayed in the status field.
When turning on the power supply again, NCW-3DHIP doesn't issue a DHCP request.
Note
The above operation sets Bit0-3: Startup Configuration in attribute 3 (Configuration Control) of the TCP/IP
Interface object to "0: The device use the previously saved interface setting value."
After this setting, the IP address setting via BOOTP/DHCP will not be accepted.
To set the IP address setting via BOOTP/DHCP again, do the following.
(1) Shut off the power to NCW-3DHIP.
(2) Set the Host address rotary switch (IP.ADR ×16, ×1) on the panel of NCW-3DHIP to FF (255).
(3) Supply the power to NCW-3DHIP.
At this time, "2: The device obtain its interface configuration values via DHCP.(Default)" is set to Bit0-3:
Startup Configuration in attribute 3 (Configuration Control) of the TCP/IP Interface object.
(4) Shut off the power to NCW-3DHIP again.
(5) Set the Subnet address (IP.NET) on the panel of NCW-3DHIP to 0 (0) and the Host address rotary switch
(IP.ADR ×16, ×1) to 00 (0).
(6) Supply the power to NCW-3DHIP again.
At this time, the IP address setting via BOOTP/DHCP is available.
(9) The allocation of an IP address is completed.
