● Circuit resistance check
[Measurement method]
Measure resistance at Point A or B using a circuit tester or other appropriate device.
Have Point A connected to measure at Point B.
If the connector is off, identify the line by the wiring color.
[Check details]
Refer to the previous page for the connector pin number.
Check position
Between brown and red
Between orange and yellow
Between green and blue
*1: If checks are done at Point B, the measurement value is [Standard coil resistance + extension sensor
cable resistance].
Extension sensor cable resistance value
The resistance value of the NSD special cable is 0.2Ω/m (loop resistance).
The resistance value of the JKPEV-S cable is 0.034Ω/m (loop resistance).
Consider resistance variations due to temperature, which, relative to the standard temperature
(25 C), increases 0.4% when the temperature rises 1
o
temperature falls 1
● Insulation check
[Measurement method]
Measure using a 500 VDC insulation tester.
[Check details]
Refer to the previous page for the connector pin number.
Between brown and orange, green, shield
Between orange and green, shield
Between green and shield
Between frame and each wire or shield
NOTES
1. Make sure to disconnect the ABSOCODER sensor from the converter before carrying out insulation
checks.
2. If there is a risk that energization may cause damages to the electronic circuits in and around the
machine, remove the ABSOCODER sensor from the machine.
3. After completing the checks, short-circuit between the pins to discharge remaining voltage before
connecting the ABSOCODER sensor to the converter.
Criterion
The measured value
should be in the range of
the standard coil
resistance. *1
C.
o
Check position
101
Check position
Between brown and orange, green, shield
Between orange and green, shield
Between green and shield
Between frame and each wire or shield
C and decreases 0.4% when the
o
Criterion
10MΩ or more
Criterion
∞
