12. STORE OF MAINTENANCE INFORMATION
NCW-3DHIP can store maintenance information to the Info Maintenance object (Class ID: 0xC07).
The maintenance information should be store if it is required.
Stored information can be checked when doing periodic maintenance NCW-3DHIP or having an error.
For more details, refer to "APPENDIX 2-12. Info Maintenance Object (Class ID: 0xC7)".
No.
1 Power Distribution Time
2 Function
3 Location
4 Installation Date
5 Descriptor 1
6 Descriptor 2
7 Security
Name Data Type
UDINT
UDINT
STRING
UDINT
STRING
UDINT
STRING
UDINT
STRING
UDINT
STRING
UDINT
STRING
NCW-3DHIP cumulative energization time can be check.
Unit: sec
Stores a function code.
Stores a function comment.
Max.character No.: 58
Stores an installation location code.
Stores an installation location comment.
Max.character No.: 58
Stores an installation date code.
Stores an installation date comment.
Max.character No.: 58
Stores a descriptor 1 code.
Stores a descriptor 1 comment.
Max.character No.: 58
Stores a descriptor 2 code.
Stores a descriptor 2 comment.
Max.character No.: 58
Stores a security code.
Stores a security name comment.
Max. character No.:58
98
Description
