(3) Communication specification
Physical layer
Number of communication ports
Communication speed
(Selectable)
Communication format
(Selectable)
Communication cycle time (RPI)
Protocol
Communication
Basic protocol
Network topology
DLR function
Web server function
Recommended cable
Cable length
IP address setting
Communication setting
(Speed and format)
Parameter settings
Control (OUTPUT)
Function
Diagnosis status reference
(INPUT)
Operation and abnormality
occurrence history
Maintenance information
Communication indicator
Items
Ethernet 10Base-T, 100Base-TX, ISO/IEC 8802-3
2 (connector: RJ45）
100Mbit/s, 10Mbit/s, Auto-Negotiation
Full Duplex, Half Duplex, Auto-Negotiation
Minimum 2 ms
CIP Conformance Test CT-15
- Internet Protocol(IP version 4) (RFC 791)
- User Datagram Protocol(UDP) (RFC 768)
- Transfer Control Protocol(TCP) (RFC 793)
- Address Resolution Protocol(ARP) (RFC 826)
- Internet Control Message Protocol (ICMP) (RFC 792)
- Bootstrap Protocol(BOOTP)(RFC951)
- Dynamic Host Configuration Protocol(DHCP)(RFC2131)
- Star topology
- Linear bus topology
- Ring topology (DLR function)
CAT-5e STP straight cable
Between nodes: Max. 100m
- Sets manually by using switches on the NCW-3DHIP
panel side.
- Sets automatically from the BOOTP or DHCP server.
- Sets manually by using DIP switches on the NCW-3DHIP
rear side.
- Sets automatically by the Auto-Negotiation.
Axis Unavailable
Error Clear
Position Data Increase Direction
Preset Value
Preset (PRESET)
Error Clear (ERRCLR)
Device Not Ready (NRDY)
Device watchdog timer error (WDTE)
Device memory error (ME)
Internal I/F error (I/F ERR)
Axis-n Sensor Error (SE)
Axis-n Disconnected Sensor Error (SSE)
Axis-n Sensor Circuit Power Error (SPF)
Axis-n Sensor Data Error (DE)
Axis-n Position Data
Axis-n Previous Preset Data
Newest 32 error contents or operation histories
Cumulative energization time
Writing in and reference of maintenance information
"MS" (Green / Red) : Module status
"NS" (Green / Red) : Network status
"L/A1" (Green)
"L/A2" (Green)
7
Specifications
: Link status
: Link status
