NSD ABSOCODER NCW-3DHIPLC Specifications & Instruction Manual page 13

● Model List
◆Converter
No. Model
NCW-3DHIPLC
①
◆ABSOCODER sensor
No. Items
ABSOCODER sensor
(CYLNUC Cylinder)
(2)
ABSOCODER sensor
(CYLNUC MarkⅡ
Cylinder)
ABSOCODER sensor
(Linear type)
For more details of the ABSOCODER sensor, contact your NSD sales representatives.
◆Extension sensor cable
No. Model
4P－[1]－[2] [3]－[L]
(3)
JKPEV-S(1.25mm
◆EDS File
No.
File name:
(4)
EDS_Rev000000**_NSD_NCW-3D_IP_********.eds
For CYLNUC Cylinder and Linear type ABSOCODER sensor
Position data 24-bit binary code output
Models
SCM
SCJ
SCMJ
SCJJ
SCHH
SCAH
CSAH
MⅡM
MⅡJ
MⅡMJ
MⅡJJ
VLS-12.8PRA28
VLS-12.8MHP28
IRS-51.2P
IRS-32.8P
[1]...Cable type
S: Standard cable, RBT: Robotic cable, URT: Semi-heat-resistant robotic cable,
HRT: Heat-resistant robotic cable
[2]...Connector (Converter side)
01: Connector for connecting to a converter (R04-PB9M8.0A)
43: Standard connector (NJW-2012-PM8)
90: Crimping terminals (R-1.25-4)
[3]...Connector (Sensor side)
40: Connector for directly connecting to a sensor (NJW-2012-PF8)
44: Standard connector (NJW-2012-AdF8)
55: Large connector (NWPC-4012-P12)
90: Crimping terminals (R-1.25-4)
[L]...Cable length (m)
Contact your NSD representative for the cable length.
2 ×5P) Commercially available cable
Model
Description
Resolution: 1.5625μm
Built-in Inrodsensor
Resolution: 6.25μm
Rod sensor, resolution: 1.5625μm
Inrodsensor, resolution: 6.25μm
Inrodsensor, resolution: 4μm
Description
Download it from NSD website.
5
Descriptions
Description
