If you know the actual IP address of the device, you have to use this procedure:
Turn on the Device with the Ethernet cable inserted;
Insert the actual IP of the Converter;
Press the "Ping" button, must appear "Device Found!";
Press the "Next" button;
Select which operations you want to do;
Press the "Execute update
When all the operations are "OK" the device automatically goes at Normal Mode.
At this point the configuration/firmware on the device is correctly update.
Note:
When you install a new version of the software, if it is the first time it is better you do the update of the Firmware in the HD67677
device.
Note:
When you receive the device, for the first time, you also have to update the Firmware in the HD67677 device.
Warning:
If Fig. 11 appears when you try to do the Update try these points before seeking assistance:
Try to repeat the operations for the update;
Try with another PC;
Try to restart the PC;
If you are using the program inside a Virtual Machine, try to use it in the main
Operating System;
If you are using Windows Seven or Vista or 8, make sure that you have the
administrator privileges;
Pay attention to the Firewall lock;
Check the LAN settings.
In the case of HD67677 you have to use the software "SW67677": www.adfweb.com\download\filefold\SW67677.zip.
ADFweb.com S.r.l.
firmware" button to start the upload;
User Manual BACnet slave / CAN
Document code: MN67677_ENG Revision 1.010
Figure 11: "Protection" window
