CHARACTERISTICS:
The configurable DeviceNet to NMEA 2000 gateway allows the following characteristics:
Baud Rate changeable with software;
Mountable on Rail DIN;
Temperature range from -40°C to 85°C.
The "NMEA 2000 / DeviceNet - Converter" allows a NMEA 2000 network to communicate with a DeviceNet network.
POWER SUPPLY:
Recommended Power Supply
VDC VAC
24v 12v
VDC
Vmin Vmax Vmin
8v 35v
ADFweb.com Srl – IT31010 – Mareno – Treviso
VAC
Vmax
8v 19v
User Manual NMEA 2000 / DeviceNet
Document code: MN67251_ENG
Caution: Not reverse the polarity power
