Industrial Electronic Devices

User Manual

Revision 1.010

English

NMEA 2000 / PROFIBUS Slave -

Converter

(Order Code: HD67252-A1)

for Website information:

www.adfweb.com?Product=HD67252

for Price information:

www.adfweb.com?Price=HD67252-A1

Benefits and Main Features:

Very easy to configure

Electrical isolation

Temperature range: -40°C/85°C (-40°F/185°F)

User Manual

ADFweb.com Srl – IT31010 – Mareno – Treviso

User Manual NMEA 2000 / PROFIBUS Slave

Document code: MN67252_ENG

Revision 1.010

For others Gateways / Bridges:

CANopen to Modbus

Need help?

Do you have a question about the HD67252-A1 and is the answer not in the manual?

Questions and answers

Summary of Contents for ADF Web HD67252-A1

Page 1 Page 1 of 24 Industrial Electronic Devices User Manual Revision 1.010 English NMEA 2000 / PROFIBUS Slave - Converter (Order Code: HD67252-A1) for Website information: www.adfweb.com?Product=HD67252 for Price information: For others Gateways / Bridges: www.adfweb.com?Price=HD67252-A1 CANopen to Modbus See also the following links: Benefits and Main Features: www.adfweb.com?Product=HD67001...
Page 2: Table Of Contents
User Manual NMEA 2000 / PROFIBUS Slave Document code: MN67252_ENG Revision 1.010 Page 2 of 24 Industrial Electronic Devices INDEX: UPDATED DOCUMENTATION: Dear customer, we thank you for your attention and we remind you that you need to check that the following document is: Page INDEX Updated...
Page 3: Security Alert
User Manual NMEA 2000 / PROFIBUS Slave Document code: MN67252_ENG Revision 1.010 Page 3 of 24 Industrial Electronic Devices SECURITY ALERT: ENERAL NFORMATION To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device, legal and safety regulation are required for each individual application.
Page 4: Example Of Connection
User Manual NMEA 2000 / PROFIBUS Slave Document code: MN67252_ENG Revision 1.010 Page 4 of 24 Industrial Electronic Devices EXAMPLE OF CONNECTION: ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 5: Connection Scheme
User Manual NMEA 2000 / PROFIBUS Slave Document code: MN67252_ENG Revision 1.010 Page 5 of 24 Industrial Electronic Devices CONNECTION SCHEME: ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 6: Characteristics
User Manual NMEA 2000 / PROFIBUS Slave Document code: MN67252_ENG Revision 1.010 Page 6 of 24 Industrial Electronic Devices CHARACTERISTICS: The HD67252 is a NMEA 2000 / PROFIBUS Slave - Converter. They have the following characteristics: Triple isolation between NMEA 2000 - Power Supply, NMEA 2000 - PROFIBUS, PROFIBUS - Power Supply; Two-directional information between PROFIBUS bus and NMEA 2000 bus;...
Page 7: Power Supply
The devices can be powered at 8…19V AC and 8…35V DC. For more details see the two tables below. Vmin Vmax Vmin Vmax Consumption at 24V DC: Device Consumption [W/VA] HD67252-A1 Caution: Do not reverse the polarity power HD67252-A1 ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 8: Functions
User Manual NMEA 2000 / PROFIBUS Slave Document code: MN67252_ENG Revision 1.010 Page 8 of 24 Industrial Electronic Devices FUNCTION MODES: The device has got two function modes depending on the position of the ‘Dip2 of Dip-Switch A’: The first, with ‘Dip2 of Dip-Switch A’ at “OFF” position, is used for the normal working of the device. The second, with ‘Dip2 of Dip-Switch A’...
Page 9: Leds
User Manual NMEA 2000 / PROFIBUS Slave Document code: MN67252_ENG Revision 1.010 Page 9 of 24 Industrial Electronic Devices LEDS: The device has got three LEDs that are used to give information about the functioning status. The various meanings of the LEDs are described in the table below. Normal Mode Boot Mode 1: NMEA 2000 comm.
Page 10: Nmea 2000
User Manual NMEA 2000 / PROFIBUS Slave Document code: MN67252_ENG Revision 1.010 Page 10 of 24 Industrial Electronic Devices NMEA 2000: To terminate the NMEA 2000 line with a 120Ω resistor it is necessary that the Dip2 of ‘Dip-Switch B’ is at ON position. Cable characteristics: DC parameter: Impedance...
Page 11: Profibus
User Manual NMEA 2000 / PROFIBUS Slave Document code: MN67252_ENG Revision 1.010 Page 11 of 24 Industrial Electronic Devices PROFIBUS: The PROFIBUS uses a 9-pin D-SUB connector. The pin assignment is defined like in the right figure. Here some codes of cables: Belden: p/n 183079A - Continuous Armor DataBus®...
Page 12: Use Of Compositor Sw67252
User Manual NMEA 2000 / PROFIBUS Slave Document code: MN67252_ENG Revision 1.010 Page 12 of 24 Industrial Electronic Devices USE OF COMPOSITOR SW67252: To configure the Converter, use the available software that runs with Windows called SW67252. It is downloadable on the site www.adfweb.com and its operation is described in this document.
Page 13: New Project / Open Project
User Manual NMEA 2000 / PROFIBUS Slave Document code: MN67252_ENG Revision 1.010 Page 13 of 24 Industrial Electronic Devices NEW CONFIGURATION / OPEN CONFIGURATION: “New Configuration” button creates the folder which contains the entire device’s configuration. A device’s configuration can also be imported or exported: To clone the configurations of a programmable “NMEA 2000 / PROFIBUS - Converter”...
Page 14: Software Options
User Manual NMEA 2000 / PROFIBUS Slave Document code: MN67252_ENG Revision 1.010 Page 14 of 24 Industrial Electronic Devices SOFTWARE OPTIONS: By pressing the “Settings” ( ) button there is the possibility to change the language of the software and check the updatings for the compositor.
Page 15: Set Communication
User Manual NMEA 2000 / PROFIBUS Slave Document code: MN67252_ENG Revision 1.010 Page 15 of 24 Industrial Electronic Devices SET COMMUNICATION: This section defines the fundamental communication parameter of two Buses, NMEA 2000 and PROFIBUS. By Pressing the “Set Communication” button from the main window for SW67252 (Fig. 2) the window “Set Communication”...
Page 16: Receive Frames
User Manual NMEA 2000 / PROFIBUS Slave Document code: MN67252_ENG Revision 1.010 Page 16 of 24 Industrial Electronic Devices RECEIVE FRAMES: By pressing the “Receive Frames” button from the main window for SW67252 (Fig. 2) the “Receive NMEA 2000 Frames” window appears (Fig.
Page 17: Send Frames
User Manual NMEA 2000 / PROFIBUS Slave Document code: MN67252_ENG Revision 1.010 Page 17 of 24 Industrial Electronic Devices TRANSMIT FRAMES: By pressing the “Transmit Frames” button from the main window for SW67252 (Fig. 2) the “Transmit NMEA 2000 frames” window appears (Fig.
Page 18: Gsd File
User Manual NMEA 2000 / PROFIBUS Slave Document code: MN67252_ENG Revision 1.010 Page 18 of 24 Industrial Electronic Devices GSD FILE: By pressing the “GSD File” button from the main window for SW67252 (Fig. 2), it is possible to save the GSD file for the PROFIBUS side. Note: When you import the .gsd file on your Master PROFIBUS, you will have to add all the modules that are present inside it.
Page 19: Update Device
User Manual NMEA 2000 / PROFIBUS Slave Document code: MN67252_ENG Revision 1.010 Page 19 of 24 Industrial Electronic Devices UPDATE DEVICE: By pressing the “Update Device” button it is possible to load the created Configuration into the device; and also the Firmware, if is necessary.
Page 20 User Manual NMEA 2000 / PROFIBUS Slave Document code: MN67252_ENG Revision 1.010 Page 20 of 24 Industrial Electronic Devices Note: When you install a new version of the software it is better if the first time you do the update of the Firmware in the HD67252 device. Note: When you receive the device, for the first time, you have to update also the Firmware in the HD67252 device.
Page 21: Mechanical Dimensions
User Manual NMEA 2000 / PROFIBUS Slave Document code: MN67252_ENG Revision 1.010 Page 21 of 24 Industrial Electronic Devices MECHANICAL DIMENSIONS: Figure 8: Mechanical dimensions scheme for HD67252-A1 ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 22: Order Code
Enclosure Type A: 1M, 35mm DIN Rail mounting Device Family HD67252: NMEA 2000 / PROFIBUS Slave - Converter Order Code: HD67252-A1 NMEA 2000 / PROFIBUS Slave - Converter ACCESSORIES: Order Code: AC34001 35mm Rail DIN - Power Supply 220/240V AC 50/60Hz – 12 V AC Order Code: AC34002 35mm Rail DIN - Power Supply 110V AC 50/60Hz –...
Page 23: Disclaimer
User Manual NMEA 2000 / PROFIBUS Slave Document code: MN67252_ENG Revision 1.010 Page 23 of 24 Industrial Electronic Devices DISCLAIMER: All technical content within this document can be modified without notice. The content of the document is a under continual renewal. For losses due to fire, earthquake, third party access or other accidents, or intentional or accidental abuse, misuse, or use under abnormal conditions repairs are charged to the user.
Page 24: Warranties And Technical Support
User Manual NMEA 2000 / PROFIBUS Slave Document code: MN67252_ENG Revision 1.010 Page 24 of 24 Industrial Electronic Devices WARRANTIES AND TECHNICAL SUPPORT: For fast and easy technical support for your ADFweb.com SRL products, consult our internet support at www.adfweb.com. Otherwise contact us at the address support@adfweb.com RETURN POLICY: If while using your product you have any problem and you wish to exchange or repair it, please do the following:...
