Industrial Electronic Devices
User Manual
Revision 1.001
English
M-Bus Master / USB - Converter
(Order Codes: HD67024-B2-20,
HD67024-B2-40,
HD67024-B2-80,
HD67024-B2-160,
HD67024-B2-250)
for Website information:
www.adfweb.com?Product=HD67024
for Price information:
www.adfweb.com?Price=HD67024-B2-20
www.adfweb.com?Price=HD67024-B2-40
www.adfweb.com?Price=HD67024-B2-80
www.adfweb.com?Price=HD67024-B2-160
www.adfweb.com?Price=HD67024-B2-250
Benefits and Main Features:
Very easy to configure
Microprocessor for queue data control
Electrical isolation
Industrial temperature range:
-40°C / 70°C (-40°F / 158°F)
ADFweb.com Srl – IT31010 – Mareno – Treviso
Similiar
Products
Axis Solutions Pvt Ltd is the Authorized Distributor of
www.axisindia.in | info@axisindia.in
User Manual M-Bus Master / USB
Document code: MN67024_ENG
HD67024-B2-xxx
For other M-Bus products see also the following link:
Converter M-Bus to
www.adfweb.com?Product=HD67021
www.adfweb.com?Product=HD67022
www.adfweb.com?Product=HD67030
M-Bus Analyzer / Scanner / Sniffer
www.adfweb.com?Product=HD67031
M-Bus - Repeater - Isolator
www.adfweb.com?Product=HD67032
Converter M-Bus /
www.adfweb.com?Product=HD67029M-232
www.adfweb.com?Product=HD67029M-485
www.adfweb.com?Product=HD67044M
www.adfweb.com?Product=HD67051-B2
www.adfweb.com?Product=HD67053M
www.adfweb.com?Product=HD67058M
M-Bus – Concentrator - Datalogger
www.adfweb.com?Product=HD67054M
M-Bus – Concentrator - Datalogger
www.adfweb.com?Product=HD67057-B2-xxx
M-Bus Slave / Modbus Master - Converter
www.adfweb.com?Product=HD67059M-232
Do you need to choose a device? do you want help?
Ask it to the following link:
www.adfweb.com?Cmd=helpme
INFO:
www.adfweb.com
in India
Revision 1.001
Page 1 of 16
(RS232)
(RS485)
(Ethernet)
(Modbus on RS232)
(Modbus on RS485)
(Modbus TCP)
(CANopen)
(PROFIBUS)
(DeviceNet Slave)
Phone +39.0438.30.91.31
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for ADF Web AXIS HD67024-B2-20
Summary of Contents for ADF Web AXIS HD67024-B2-20
- Page 1 User Manual M-Bus Master / USB Document code: MN67024_ENG Revision 1.001 Page 1 of 16 Industrial Electronic Devices User Manual Revision 1.001 English M-Bus Master / USB - Converter (Order Codes: HD67024-B2-20, HD67024-B2-40, HD67024-B2-xxx HD67024-B2-80, HD67024-B2-160, HD67024-B2-250) For other M-Bus products see also the following link: Converter M-Bus to for Website information: www.adfweb.com?Product=HD67021...
- Page 2 User Manual M-Bus Master / USB Document code: MN67024_ENG Revision 1.001 Page 2 of 16 Industrial Electronic Devices INDEX: UPDATED DOCUMENTATION: Dear customer, we thank you for your attention and we remind you that you need to check that the following document is: Page INDEX Updated...
- Page 3 User Manual M-Bus Master / USB Document code: MN67024_ENG Revision 1.001 Page 3 of 16 Industrial Electronic Devices SECURITY ALERT: ENERAL NFORMATION To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device are required for each individual application, legal and safety regulation.
- Page 4 User Manual M-Bus Master / USB Document code: MN67024_ENG Revision 1.001 Page 4 of 16 Industrial Electronic Devices CONNECTION SCHEMES: Figure 1: Connection scheme for HD67024-B2-xxx ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
- Page 5 User Manual M-Bus Master / USB Document code: MN67024_ENG Revision 1.001 Page 5 of 16 Industrial Electronic Devices CHARACTERISTICS: The HD67024-B2-xxx is a M-Bus to USB Converter. The USB line is see like a Virtual COM Port (VCP). The control by microprocessor with 32 bits makes it particularly suitable for supervisor software and the connection to a Personal Computer. The M-Bus to USB Gateway allows the following characteristics: Baud Rate and Parity changeable with software;...
- Page 6 User Manual M-Bus Master / USB Document code: MN67024_ENG Revision 1.001 Page 6 of 16 Industrial Electronic Devices POWER SUPPLY: The devices can be powered at 15…21V AC and 18…35V DC. The consumption depends to the code of the device. For more details see the two tables below.
- Page 7 User Manual M-Bus Master / USB Document code: MN67024_ENG Revision 1.001 Page 7 of 16 Industrial Electronic Devices FUNCTION MODES: The device has got two functions mode depending of the position of the ‘Dip.2 of Dip-Switch A’: The first, with Dip2 at OFF position (factory setting), is used for the normal working of the device. The second, with Dip2 at ON position, is used for upload the Firmware/Project.
- Page 8 User Manual M-Bus Master / USB Document code: MN67024_ENG Revision 1.001 Page 8 of 16 Industrial Electronic Devices LEDS: The device has got three LEDs that are used to give information of the functioning status. The various meanings of the LEDs are described in the table below. Normal Mode Boot Mode 1: Device State...
- Page 9 User Manual M-Bus Master / USB Document code: MN67024_ENG Revision 1.001 Page 9 of 16 Industrial Electronic Devices SET COMMUNICATION PARAMETERS: Configurable Parameters: Baud Rate of USB from 300 to 115200 bps and M-Bus from 300 to 38400 bps; Parity of USB and M-Bus with None/Odd/Even. Fixed Parameters: 1 Bit Start;...
- Page 10 User Manual M-Bus Master / USB Document code: MN67024_ENG Revision 1.001 Page 10 of 16 Industrial Electronic Devices USE OF SW67024 USB FROM/TO M-BUS: To configure the board, use the available software that runs with Windows, called SW67024. It is downloadable on the site www.adfweb.com and its operation is described in this document.
- Page 11 User Manual M-Bus Master / USB Document code: MN67024_ENG Revision 1.001 Page 11 of 16 Industrial Electronic Devices The functions described above shall be made when the device is in Boot. For more details about Boot see "Connection Scheme" (Fig. 1). If it is necessary to update the firmware the button "Update Firmware"...
- Page 12 User Manual M-Bus Master / USB Document code: MN67024_ENG Revision 1.001 Page 12 of 16 Industrial Electronic Devices CHARACTERISTICS OF THE CABLES: USB: The USB connector (Connector3) is a Type-B Female. So the cable must be a Type-B Male. A two wire standard telephone cable (JYStY N*2*0.8 mm) is used as the transmission medium for the M-Bus. The maximum distance between a slave and the repeater is 350m;...
- Page 13 User Manual M-Bus Master / USB Document code: MN67024_ENG Revision 1.001 Page 13 of 16 Industrial Electronic Devices MECHANICAL DIMENSIONS: ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31 Figure 3: Mechanical dimensions scheme for HD67024-B2 -20 -40 -80 -160 Figure 4: Mechanical dimensions scheme for HD67024-B2-250...
- Page 14 User Manual M-Bus Master / USB Document code: MN67024_ENG Revision 1.001 Page 14 of 16 Industrial Electronic Devices ORDER CODES: Order Code: HD67024-B2-20 M-Bus Master / USB – Converter (up to 20 slaves connected to M-Bus) Order Code: HD67024-B2-40 M-Bus Master / USB – Converter (up to 40 slaves connected to M-Bus) Order Code: HD67024-B2-80 M-Bus Master / USB –...
- Page 15 User Manual M-Bus Master / USB Document code: MN67024_ENG Revision 1.001 Page 15 of 16 Industrial Electronic Devices DISCLAIMER All technical content within this document can be modified without notice. The content of the document content is a recurring audit. For losses due to fire, earthquake, third party access or other accidents, or intentional or accidental abuse, misuse, or use under abnormal conditions repairs are charged to the user.
- Page 16 User Manual M-Bus Master / USB Document code: MN67024_ENG Revision 1.001 Page 16 of 16 Industrial Electronic Devices WARRANTIES AND TECHNICAL SUPPORT: For fast and easy technical support for your ADFweb.com SRL products, consult our internet support at www.adfweb.com. Otherwise contact us at the address support@adfweb.com RETURN POLICY: If while using your product you have any problem and you wish to exchange or repair it, please do the following: 1) Obtain a Product Return Number (PRN) from our internet support at www.adfweb.com.
