Industrial Electronic Devices

User Manual

Revision 1.001

English

NMEA 2000 / DeviceNet -

Converter

(Order Code: HD67251-A1 - HD67251-A3 - HD67251-A4)

for Website information:

www.adfweb.com?Product=HD67251-A1

www.adfweb.com?Product=HD67251-A3

www.adfweb.com?Product=HD67251-A4

for Price information:

www.adfweb.com?Price=HD67251-A1

www.adfweb.com?Price=HD67251-A3

www.adfweb.com?Price=HD67251-A4

Benefits and Main Features:

Very easy to configure

Low cost

Designed for serious use

Industrial temperature range:

-40°C / 85°C (-40F / 185°F)

ADFweb.com Srl – IT31010 – Mareno – Treviso

Axis Solutions Pvt Ltd is the Authorized Distributor of

www.axisindia.in | info@axisindia.in

User Manual NMEA 2000 / DeviceNet

Document code: MN67251_ENG

Revision 1.001

HD67251-A3

HD67251-A1

HD67251-A3

For others Gateways / Bridges:

NMEA 2000 to Modbus

Need help?

Do you have a question about the HD67251-A1 and is the answer not in the manual?

Questions and answers

Summary of Contents for ADF Web HD67251-A1

Page 1 English NMEA 2000 / DeviceNet - Converter HD67251-A4 HD67251-A3 HD67251-A1 HD67251-A4 HD67251-A3 (Order Code: HD67251-A1 - HD67251-A3 - HD67251-A4) For others Gateways / Bridges: for Website information: www.adfweb.com?Product=HD67251-A1 NMEA 2000 to Modbus www.adfweb.com?Product=HD67251-A3 See also the following links: www.adfweb.com?Product=HD67251-A4 www.adfweb.com?Product=HD67222...
Page 2 User Manual NMEA 2000 / DeviceNet Document code: MN67251_ENG Revision 1.001 Page 2 of 18 Industrial Electronic Devices INDEX: UPDATED DOCUMENTATION: Dear customer, we thank you for your attention and we remind you that you Page need to check that the following document is: INDEX Updated UPDATED DOCUMENTATION...
Page 3 User Manual NMEA 2000 / DeviceNet Document code: MN67251_ENG Revision 1.001 Page 3 of 18 Industrial Electronic Devices SECURITY ALERT: ENERAL NFORMATION To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device are required for each individual application, legal and safety regulation.
Page 4 User Manual NMEA 2000 / DeviceNet Document code: MN67251_ENG Revision 1.001 Page 4 of 18 Industrial Electronic Devices CONNECTION SCHEMES: Figure 1: Connection scheme for HD67251-A1 ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 5 User Manual NMEA 2000 / DeviceNet Document code: MN67251_ENG Revision 1.001 Page 5 of 18 Industrial Electronic Devices Figure 2: Connection scheme for HD67251-A3 ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 6 User Manual NMEA 2000 / DeviceNet Document code: MN67251_ENG Revision 1.001 Page 6 of 18 Industrial Electronic Devices Figure 3: Connection scheme for HD67251-A4 ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 7 User Manual NMEA 2000 / DeviceNet Document code: MN67251_ENG Revision 1.001 Page 7 of 18 Industrial Electronic Devices CHARACTERISTICS: The configurable DeviceNet to NMEA 2000 gateway allows the following characteristics: Baud Rate changeable with software; Mountable on Rail DIN; Temperature range from -40°C to 85°C. The “NMEA 2000 / DeviceNet - Converter”...
Page 8 User Manual NMEA 2000 / DeviceNet Document code: MN67251_ENG Revision 1.001 Page 8 of 18 Industrial Electronic Devices CONFIGURATION: You need Compositor SW67251 software on your PC in order to perform the following: Define the parameters of two buses; Define which NMEA 2000 frames are reading from the DeviceNet;...
Page 9 User Manual NMEA 2000 / DeviceNet Document code: MN67251_ENG Revision 1.001 Page 9 of 18 Industrial Electronic Devices NEW PROJECT / OPEN PROJECT: The “New Project” button creates the folder which contains the entire device configuration. A device configuration can also be imported and exported: To clone the configurations of a Programmable DeviceNet to NMEA 2000 Converter in order to configure another device in the same manner, it is necessary to maintain the folder and all its contents;...
Page 10 User Manual NMEA 2000 / DeviceNet Document code: MN67251_ENG Revision 1.001 Page 10 of 18 Industrial Electronic Devices SET COMMUNICATION: This section defines the fundamental communication parameters of two Buses, DeviceNet and NMEA 2000. By pressing the “Set Communication” button from the main window for SW67251 (Fig. 4) the window “Set Communication”...
Page 11 User Manual NMEA 2000 / DeviceNet Document code: MN67251_ENG Revision 1.001 Page 11 of 18 Industrial Electronic Devices RECEIVE FRAMES: By pressing the “Receive Frames” button from the main window for SW67251 (Fig. 4) the “Receive Frames” window appears (Fig. 6). The data of the columns have the following meanings: In the field “Data Page”...
Page 12 User Manual NMEA 2000 / DeviceNet Document code: MN67251_ENG Revision 1.001 Page 12 of 18 Industrial Electronic Devices SEND FRAMES: By pressing the “Send Frames” button from the main window of SW67251 (Fig. 4) the “Send Frames” window appears (Fig. 7). The data of the columns have the following meanings: In the field “Priority”...
Page 13 User Manual NMEA 2000 / DeviceNet Document code: MN67251_ENG Revision 1.001 Page 13 of 18 Industrial Electronic Devices UPDATE DEVICE: Section “Update Via Serial” (Fig. 6): In order to load the parameters or update the firmware in the gateway, follow these instructions: Turn off the device;...
Page 14 User Manual NMEA 2000 / DeviceNet Document code: MN67251_ENG Revision 1.001 Page 14 of 18 Industrial Electronic Devices CHARACTERISTICS OF THE CABLES: The connection from RS232 socket to a serial port (example one from a personal computer), must be made with a Null Modem cable (a serial cable where the pins 2 and 3 are crossed).
Page 15 Revision 1.001 Page 15 of 18 Industrial Electronic Devices MECHANICAL DIMENSIONS: Figure 11: Mechanical dimensions scheme HD67251-A3 Figure 10: Mechanical dimensions scheme HD67251-A1 Figure 12: Mechanical dimensions scheme HD67251-A4 ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 16 Document code: MN67251_ENG Revision 1.001 Page 16 of 18 Industrial Electronic Devices ORDER CODE: Order Code: HD67251-A1 - NMEA 2000 / DeviceNet - Converter Order Code: HD67251-A3 - NMEA 2000 / DeviceNet - Converter Order Code: HD67251-A4 - NMEA 2000 / DeviceNet - Converter...
Page 17 User Manual NMEA 2000 / DeviceNet Document code: MN67251_ENG Revision 1.001 Page 17 of 18 Industrial Electronic Devices DISCLAIMER All technical content within this document can be modified without notice. The content of the document content is a recurring audit. For losses due to fire, earthquake, third party access or other accidents, or intentional or accidental abuse, misuse, or use under abnormal conditions repairs are charged to the user.
Page 18 User Manual NMEA 2000 / DeviceNet Document code: MN67251_ENG Revision 1.001 Page 18 of 18 Industrial Electronic Devices WARRANTIES AND TECHNICAL SUPPORT: For fast and easy technical support for your ADFweb.com SRL products, consult our internet support at www.adfweb.com. Otherwise contact us at the address support@adfweb.com RETURN POLICY: If while using your product you have any problem and you wish to exchange or repair it, please do the following: 1) Obtain a Product Return Number (PRN) from our internet support at www.adfweb.com.
