Industrial Electronic Devices

User Manual

Revision 2.000

English

DeviceNet Slave / CAN - Converter

(Order Code: HD67235-A1, HD67235-A3, HD67235-A4)

For Website information:

www.adfweb.com?Product=HD67235-A1

www.adfweb.com?Product=HD67235-A3

www.adfweb.com?Product=HD67235-A4

For Price information:

www.adfweb.com?Price=HD67235-A1

www.adfweb.com?Price=HD67235-A3

www.adfweb.com?Price=HD67235-A4

Benefits and Main Features:

Very easy to configure

Triple electrical isolation

Ethernet programmation

Temperature range: -40°C/85°C (-40°F/185°F)

User Manual

ADFweb.com S.r.l.

User Manual DeviceNet Slave / CAN - Converter

Document code: MN67235_ENG

Revision 2.000

For others Gateways / Bridges:

CANopen to DeviceNet

Need help?

Do you have a question about the HD67235-A1 and is the answer not in the manual?

Questions and answers

Summary of Contents for ADF Web HD67235-A1

Page 1 Revision 2.000 Page 1 of 26 Industrial Electronic Devices User Manual Revision 2.000 English DeviceNet Slave / CAN - Converter (Order Code: HD67235-A1, HD67235-A3, HD67235-A4) For Website information: www.adfweb.com?Product=HD67235-A1 www.adfweb.com?Product=HD67235-A3 www.adfweb.com?Product=HD67235-A4 For Price information: For others Gateways / Bridges: www.adfweb.com?Price=HD67235-A1 CANopen to DeviceNet www.adfweb.com?Price=HD67235-A3...
Page 2: Updated Documentation
User Manual DeviceNet Slave / CAN - Converter Document code: MN67235_ENG Revision 2.000 Page 2 of 26 Industrial Electronic Devices INDEX: UPDATED DOCUMENTATION: Dear customer, we thank you for your attention and we remind you Page that you need to check that the following document is: INDEX UPDATED DOCUMENTATION Updated...
Page 3: Security Alert
User Manual DeviceNet Slave / CAN - Converter Document code: MN67235_ENG Revision 2.000 Page 3 of 26 Industrial Electronic Devices SECURITY ALERT: ENERAL NFORMATION To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device, legal and safety regulation are required for each individual application.
Page 4: Example Of Connection
User Manual DeviceNet Slave / CAN - Converter Document code: MN67235_ENG Revision 2.000 Page 4 of 26 Industrial Electronic Devices EXAMPLE OF CONNECTION: ADFweb.com S.r.l.
Page 5: Connection Scheme
User Manual DeviceNet Slave / CAN - Converter Document code: MN67235_ENG Revision 2.000 Page 5 of 26 Industrial Electronic Devices CONNECTION SCHEME: Figure 1a: Connection scheme for HD67235-A1 ADFweb.com S.r.l.
Page 6 User Manual DeviceNet Slave / CAN - Converter Document code: MN67235_ENG Revision 2.000 Page 6 of 26 Industrial Electronic Devices Figure 1b: Connection scheme for HD67235-A3 ADFweb.com S.r.l.
Page 7 User Manual DeviceNet Slave / CAN - Converter Document code: MN67235_ENG Revision 2.000 Page 7 of 26 Industrial Electronic Devices Figure 1c: Connection scheme for HD67235-A4 ADFweb.com S.r.l.
Page 8 Page 8 of 26 Industrial Electronic Devices CHARACTERISTICS: The HD67235-A1, HD67235-A3 and HD67235-A4 are converters from DeviceNet slave to CAN and vice-versa. They allows the following characteristics: Up to 455 bytes in reading and 455 bytes in writing; Triple isolation between CAN - Power Supply, CAN - DeviceNet, Power Supply - DeviceNet.
Page 9: Power Supply
Industrial Electronic Devices POWER SUPPLY: The devices can be powered at 8…24V AC and 12…35V DC. For more details see the two tables below. Vmin Vmax Vmin Vmax HD67235-A1 Consumption at 24V DC: Device Consumption [W/VA] HD67671-IP-2-A1 HD67671-IP-4-A1 HD67671-MSTP-2-A1 HD67235-A3...
Page 10: Function Modes
User Manual DeviceNet Slave / CAN - Converter Document code: MN67235_ENG Revision 2.000 Page 10 of 26 Industrial Electronic Devices FUNCTION MODES: The device has got two functions mode depending of the position of the ‘Dip2 of Dip-Switch A’: The first, with ‘Dip2 of Dip-Switch A’ at “OFF” position, is used for the normal working of the device. The second, with ‘Dip2 of Dip-Switch A’...
Page 11 User Manual DeviceNet Slave / CAN - Converter Document code: MN67235_ENG Revision 2.000 Page 11 of 26 Industrial Electronic Devices LEDS: The device has got four LEDs that are used to give information about the functioning status. The various meanings of the LEDs are described in the table below. Normal Mode Boot Mode Blinks quickly: Boot state...
Page 12 User Manual DeviceNet Slave / CAN - Converter Document code: MN67235_ENG Revision 2.000 Page 12 of 26 Industrial Electronic Devices CAN: For terminate the CAN line with a 120Ω resistor it is necessary that the Dip1 of ‘Dip-Switch B’ is at ON position. Cable characteristics: DC parameter: Impedance...
Page 13 User Manual DeviceNet Slave / CAN - Converter Document code: MN67235_ENG Revision 2.000 Page 13 of 26 Industrial Electronic Devices DEVICENET: For terminate the DeviceNet line with a 120Ω resistor it is necessary that the Dip1 of ‘Dip-Switch C’ is at ON position. Cable characteristics: DC parameter: Impedance...
Page 14 User Manual DeviceNet Slave / CAN - Converter Document code: MN67235_ENG Revision 2.000 Page 14 of 26 Industrial Electronic Devices USE OF COMPOSITOR SW67235: To configure the Converter, use the available software that runs with Windows called SW67235. It is downloadable from the site www.adfweb.com and its operation is described in this document (this manual is referenced to the last version of the software present on our web site).
Page 15: New Configuration / Open Configuration
User Manual DeviceNet Slave / CAN - Converter Document code: MN67235_ENG Revision 2.000 Page 15 of 26 Industrial Electronic Devices NEW CONFIGURATION / OPEN CONFIGURATION: “New Configuration” button creates the folder which contains the entire device’s configuration. A device’s configuration can also be imported or exported: To clone the configurations of a Programmable “DeviceNet slave / CAN - Converter”...
Page 16: Software Options
User Manual DeviceNet Slave / CAN - Converter Document code: MN67235_ENG Revision 2.000 Page 16 of 26 Industrial Electronic Devices SOFTWARE OPTIONS: By pressing the “Settings” ( ) button there is the possibility to change the language of the software and check the updatings for the compositor.
Page 17 User Manual DeviceNet Slave / CAN - Converter Document code: MN67235_ENG Revision 2.000 Page 17 of 26 Industrial Electronic Devices In the section “Software Settings” it is possible to enable or disable some addictional functions: By checking the field “Jump into next field in the tables by pressing the Enter Key”...
Page 18: Set Communication
User Manual DeviceNet Slave / CAN - Converter Document code: MN67235_ENG Revision 2.000 Page 18 of 26 Industrial Electronic Devices SET COMMUNICATION: This section define the fundamental communication parameters of two buses, DeviceNet and CAN. By Pressing the “Set Communication” button from the main window for SW67235 (Fig. 2) the window “Set Communication”...
Page 19: Receive Frames
User Manual DeviceNet Slave / CAN - Converter Document code: MN67235_ENG Revision 2.000 Page 19 of 26 Industrial Electronic Devices RECEIVE FRAMES: By pressing the “Receive Frames” button from the main window for SW67235 (Fig. 2) the “Receive Frames” window appears (Fig. 4). The COB inserted in this table contains the Output data of DeviceNet.
Page 20: Send Frames
User Manual DeviceNet Slave / CAN - Converter Document code: MN67235_ENG Revision 2.000 Page 20 of 26 Industrial Electronic Devices SEND FRAMES: By pressing the “Send Frames” button from the main window for SW67235 (Fig. 2) the “Send frames” window appears (Fig. 5). The COB inserted in this table contains the Input data of DeviceNet.
Page 21: Update Device
User Manual DeviceNet Slave / CAN - Converter Document code: MN67235_ENG Revision 2.000 Page 21 of 26 Industrial Electronic Devices UPDATE DEVICE: By pressing the “Update Device” button, it is possible to load the created Configuration into the device; and also the Firmware, if necessary. If you don’t know the actual IP address of the device you have to use this procedure: Turn off the Device;...
Page 22 At this point the configuration/firmware on the device is correctly update. Note: When you install a new version of the software, if it is the first time it is better you do the update of the Firmware in the HD67235-A1 device.
Page 23: Mechanical Dimensions
User Manual DeviceNet Slave / CAN - Converter Document code: MN67235_ENG Revision 2.000 Page 23 of 26 Industrial Electronic Devices MECHANICAL DIMENSIONS: Figure 8a: Mechanical dimensions scheme for HD67235-A1 Figure 8b: Mechanical dimensions scheme for HD67235-A3 Figure 8c: Mechanical dimensions scheme for HD67235-A4 ADFweb.com S.r.l.
Page 24: Ordering Informations
Enclosure Type A: 1M, 35mm DIN Rail mounting Device Family HD67235: DeviceNet slave / CAN - Converter Order Code: HD67235-A1 DeviceNet slave / CAN – Converter (Removable screw terminal connectors) Order Code: HD67235-A3 DeviceNet slave / CAN – Converter (M12 connectors) Order Code: HD67235-A4 DeviceNet slave / CAN –...
Page 25 User Manual DeviceNet Slave / CAN - Converter Document code: MN67235_ENG Revision 2.000 Page 25 of 26 Industrial Electronic Devices DISCLAIMER: All technical content within this document can be modified without notice. The content of the document is a under continual renewal. For losses due to fire, earthquake, third party access or other accidents, or intentional or accidental abuse, misuse, or use under abnormal conditions repairs are charged to the user.
Page 26: Warranties And Technical Support
User Manual DeviceNet Slave / CAN - Converter Document code: MN67235_ENG Revision 2.000 Page 26 of 26 Industrial Electronic Devices WARRANTIES AND TECHNICAL SUPPORT: For fast and easy technical support for your ADFweb.com SRL products, consult our internet support at www.adfweb.com. Otherwise contact us at the address support@adfweb.com RETURN POLICY: If while using your product you have any problem and you wish to exchange or repair it, please do the following:...
