Manual Span - SMC Networks IP8001 Series Operation Manual

Manual Span setting
< Value setting >
< Ratio setting >
Zero span setting can be selected. If selected, the setting method
can be selected, and the set value can be changed. Action can
confirm the set value, but cannot change it.
< Adjustment >
Devicd set up → Detailed set up → Set up → Detail setup →
Manual Span Status
[Menu Tree No.：1-3-5-7-4]
No.
From "Manual Span Status", select (OFF) if "Manual Span
Status" is not set. If "Manual Span Status" is set, select
1
(Value) or (Rate).
Lower limit value (PV 0% Side) and upper limit value (PV 100%
Side) can be specified.
< Adjustment >
Devicd set up → Detailed set up → Set up → Detail setup →
Manual Span → Value Mode
[Menu Tree No.：1-3-5-7-4-2]
No.
Select (Value) of "Manual Span Status".
1
Set lower limit value within the range of -20.0 to 60.0% with
2
"PV0% Side".
Set upper limit value within the range of 40.0 to 120.0 % with
3
"PV100% Side".
Used when all valve stroke (incl. over travel) and operation stroke
are known.
< Adjustment >
Devicd set up → Detailed set up → Set up → Detail setup →
Manual Span → Rate Mode
[Menu Tree No.：1-3-5-7-4-2]
No.
Select (Rate) of "Manual Span Status".
1
Select 100% or 0% with "Side of Overtravel".
2
Set full stroke (0.1 to 999.9) with "Full Stroke".
3
Set stroke to be used (60 to 100% of full stroke) with "Use
4
Stroke".
