■Manual Mode Setting [Menu Tree No.: 1-3-5-4]
Devicd set up → Detailed set up → Set up → Manual Operation
and change. If the positioner is operated with manual mode, change the operation mode to manual
mode.
Item
1 Opr Mode
2 Set Signal
3 Position
4 Deviation

■Calibration

[Menu Tree No.: 1-3-5-5]
Devicd set up → Detailed set up → Set up → Calibration
change. Items can be executed only during parameter mode.
Item
1 Opr Mode
2 Cal Error Status
3 Angle
4 Simple Bal Cur
5 Span Calibration
6 Input 4-20mA Cal
Balance Current
7
8 Output 4-20mA Cal
＊
5
Default
9
3: Refer "■Error Status List" for error status details. And recalibrate according to "■Error Status List".
: Becomes operable after initial adjustment is completed.
: After execution, status becomes "not calibration". Use the positioner after performing "■Initial Adjustment".
Operation mode can be changed.
Input value can be input during manual mode. Other than
manual mode, currently input value is displayed in "%".
Display present position value in "%".
Display position deviation to current input value in "%".
Operation mode can be changed
Display error info. occurred during calibration
Feedback lever angle can be confirmed.
Simple adjustment of balance current is available.
Adjust zero/span. Depends on adjustment, full calibration, span
calibration, PID + balance adjustment can be executed.
Input signal calibration can be executed.
Present balance current adjustment condition can be confirmed.
＊
4 "0" means correct condition. If figure other than "0" is displayed,
turn the adjustment screw so that the display becomes "0".
Analog output calibration can be executed.
All parameters returns to ex-factory status
1010
Select items below to confirm
Content
Select items below to confirm and
Content
＊
3
.
A
No.IP8S-OM00013
