Enforced open/close

Dead band

Valve characteristics
(Enable) and (Disable) of forced fully-close / fully-open setting can
be set independently for fully-close side and fully-open side.
(Enable) is set for fully-close setting and fully-open setting for the
default value at ex-factory.
< Setting method >
Devicd set up → Detailed set up → Set up → Detail setup →

Enforced Opn/Cls

[Menu Tree No.: 1-3-5-7-5]
No.
Select "0% Side" (Enable) or (Disable).
1
Set lower limit within 0.0 to 10.0% with "0% Value"
2
Select "100% Side" (Enable) or (Disable).
3
Set upper limit within 90.0 to 100.0% with "100% Value".
4
Set dead band.
< Setting method >
Devicd set up → Detailed set up → Set up → Detail setup →
Dead Band
[Menu Tree No.：1-3-5-7-6]
No.
1 Change within 0.0 to 10.0%.
Valve open degree character(Linear, Equal percentage 1:25 and
1:50, Quick opening 25:1 and 50:1) can be selected. Polygobnal
line with 11 dots can be set for custome setting. Operation setting
of custom setting is not supported.
< Setting >
Devicd set up → Detailed set up → Set up → Detail setup →

Valve Char

[Menu Tree No.: 1-3-5-7-7]
No.
Select valve character function with "Valve Char"
1
If "Custom" is selected in item 1, change items within -20.0
2
to 120.0% with "Custom Char".
2727
Procedure
Procedure
Procedure
