<3. Confirmation and Change of Maintenance Setting [Menu Tree No.: 1-3-5-2-3] >
Devicd set up → Detailed set up → Set up → Device Data → Maint Info
confirm and change. Items can be changed only during parameter mode. During auto mode and
manual mode, change the operation mode to parameter mode.
Item
1 Opr Mode
2 Last Date
3 Next Date
4 Maint Interval
Acc Opr Time
5
2: Accumulation is made every hour. If input current is cut before one hour passed from the last count,
accumulation less than one hour is reset. If input current is cut after 1 hour and 45min., accumulation time
is regarded as 1 hour, and the next accumulation starts from 1hour when input current is applied.
■Confirmation and Change of Positioner Operating Conditions [Menu Tree No.: 1-3-5-3]
Devicd set up → Detailed set up → Set up → Dynamic Variables
and change.
Items
1 Position
2 Setpoint
3 Deviation
4 Out1 Status
5 Out2 Status
6 Analog Output
7 Status
8 Num resp preams
9 Config Change Counter
Operation mode can be changed
Input the last maintenance date. "Acc Opr Time" is reset by
inputting final maintenance date.
User input the next maintenance date.
Input maintenance time interval in "hours".
If "Maint Interval" is input, positioner operation time starts to be
＊
accumulated from the time of inputting "Last Date". It is
2
displayed in "hours".
Displays current position value in "%".
Display current input value in "%".
Display position deviation to current input value in "%".
OUT1 alarm output condition can be confirmed. "ON" during
output, and "OFF" during not output.
OUT2 alarm output condition can be confirmed. "ON" during
output, and "OFF" during not output.
Analog output value being output can be confirmed. Displayed
in "%".
OUT1 alarm
maintenance time overrun can be confirmed.
Positioner's individual preamble figure can be confirmed. Can be
changed to value in 5 to 20.
Displays the time of positioner's parameter setting change. User
can not reset this.
Content
Content
and OUT2 alarm
99
Select items below to
Select items below to confirm
output condition,
