Initial Adjustment

1. Before starting initial setting, mount, pipe and wire the positioner referring the operation
manual "SMART POSITIONER (No.:IP8S-OM00009)".
2. Pay attention to your surroundings when performing the initial adjustment because it
causes the positioner to automatically move the actuator.
(1) Change is not applied until pressing "Send" button after changing operation mode.
After changing the operation mode, press "Send" button.
(2) Correct value is not displayed in "Position", "Set point", and "Deviation" if initial
adjustment is not correctly made.

■Change of Parameters for Initial Operation

If 4-20mADC of input current is applied after purchase without adjustment after mounting, positioner
can neither be started, nor moved on to auto mode
procedure below. Initial adjustment can be made with 4 to 20mADC of input current
detected after adjustment. In this case, keep adjusting referring countermeasure of "■Error Status
List".
1: Until the initial adjustment is complete, the positioner can have each parameter setting, but cannot be
operated.
2: For initial adjustment of HART communication, do not press any button on the positioner. If the operation
mode is changed local mode before initial adjustment is completed, mode can not be switched to auto
mode by button operation. That is, mode can not be returned to remote mode, and initial adjustment with
HART communication can not be made. This case, cut the input signal once, and restart the adjustment.
3: Do not change the input current during the parameter adjustment.
■Initial Adjustment
1. Selection of parameter
mode
Warning
!
＊ ＊
1, 2
Calibration is available only during parameter mode. Before
calibration, change operation mode to parameter mode referring
procedure below. Do not forget to press "Send" button after
changing the mode to make the change valid.
< Setting method >
Devicd set up → Detailed set up → Set up → Calibration →
Opr Mode → Pm
[Menu Tree No.: 1-3-5-5-1]
1717
. Perform initial adjustment according to
A
＊
3
. Error may be
No.IP8S-OM00013
