Confirmation and Change of Device Information

■Confirmation and Change of Device Information
<1. Confirmation and Change of Positioner Information [Menu Tree No.: 1-3-5-2-1] >
Devicd set up → Detailed set up → Set up → Device Data → Positioner Data
and confirm and change.
Item
1 Device ID
2 Mfr Date
3 Device Name
＊
1
4 Trvl Time
5 Sensor Serial No.
6 Revision Info
1: Direct direction (Dir) means the direction in which operation is started by air output from "OUT1" port of
main unit of positioner. Reverse direction (Rev.) means direction in which operation is started by air output
from "OUT2" port of main unit of positioner.
<2.Confirmation and Change of HART Communication Setting [Menu Tree No.: 1-3-5-2-2] >
Devicd set up → Detailed set up → Set up → Device Data → HART Config
below to confirm and change. Setting change is available in auto, manual, parameter mode.
Item
1 Tag
2 Long Tag
3 Descriptor
4 Date
5 Poll Addr
6 Message
7 Final Asmbly Num
Positioner board ID info. can be confirmed.
Manufacturing date of board used in IP8001 smart positioner
can be confirmed.
Device name can be confirmed. "SMC POSITIONER" is
displayed.
Actuator "Dir Speed", "Rev Speed" which are automatically
measured during full calibration and PID adjustment are
displayed in "second".
Potentiometer's serial No. can be confirmed.
Revision of HART protocol which is used for
Universal rev communication
displayed.
Hardware rev Revision of positioner board is displayed.
Software rev Revision of positioner software is displayed
Confirm and change the tag assigned to positioner. Tag is used
to identify connected positioner. Characters can be input up to
eight.
Confirm and change long tag assigned to positioner. Long tag is
used to identify connected positioner. Characters can be input
up to thirty three.
User can input information. No specified usage. Characters can
be input up to sixteen.
User can specify date. No specified usage.
Positioner's address. Set "0" when communicate with positioner
directly. Set 0 to 15 when multiple device are used in the same
loop like split range or multi-drop. Depends on setting, 375/475
field communicator settings need to be changed.
User can input message. No specified usage. Characters can be
input up to thirty two.
Confirm and change special control number like the final setting
date.
88
Select items below
Content
with HART
Content
A
protocol is
Select items
