Introduction

IP8001 Smart Positioner provides HART protocol communication as an option. Calibration,
operation setting, and data confirmation become available by using 375/475 field communicator or
AMS™ Suite: Intelligent Device Manager
operation.
This operation manual specifies HART communication functions only. Operation manual of "SMART
POSITIONER (No.:IP8S-OM00009)" shall be referred for basic operation of IP8001 smart
positioner.
Notice) AMS™ Suite: Intelligent Device Manager
Co.
Specifications
Other than HART communication, specifications are the same as basic type. Refer "■Specification"
of operation manual of "SMART POSITIONER (No.:IP8S-OM00009)" for specifications.

Function of HART Communication

Table 1 shows main functions of HART communication.
Content
Confirmation and change of
device
Confirmation of operation
Calibration
Operation setting and change
Ｒ
. Refer each other's manual of EMERSON for the
Ｒ
is the registered trademark of Emerson Electric
Table 1
Details
Confirmation and change of positioner information
Setting and confirmation of maintenance time
Confirmation and change of HART communication setting
Confirmation of actuator open degree
Confirmation of input current
Confirmation of analog output, alarm output
Confirmation of alarm status
Auto zero span adjustment
Confirmation of feedback lever angle
Confirmation of balance current
Correction of input current, analog output
Initialize
Operation direction setting
Split range setting
Manual span setting
Forced fully open/fully close setting
Valve open degree character setting
PID constant setting
55
A
No.IP8S-OM00013
