SMC Networks IP8001 Series Operation Manual page 32

＊
＜Span Calibration ＞
5
＜PID+BC adjustment＞
Input 4-20mA Calibration
Adjust zero point / span. Unlike Full Calibration, PID constant
automatic setting is not performed. PID set once remains valid. This
function is used when only zero-span adjustment is necessary.
< Adjustment >
Devicd set up → Detailed set up → Set up → Calibration → Span
Calibration → Span Calibration
[Menu Tree No.: 1-3-5-5-5-2]
No.
"Calibration Start?" is displayed. After confirming no
possibility of hazard even if the actuator operate, press "OK"
1
＊
9
.
Zero span adjustment starts and operates automatically.
2
"Span Calibration is now in Progress" is displayed.
After actuator operation stopped, confirm "Cal Error Status".
3
If display says "No Error", adjustment is completed.
5: This adjustment becomes available only after initial adjustment.
PID is automatically adjusted. Not like full calibration, zero span is
not adjusted. This becomes available when balance current
adjustment error(Balance current) is displayed.
< Setting >
Devicd set up → Detailed set up → Set up → Calibration → Span
Calibration → PID Calibration
[Menu Tree No.: 1-3-5-5-5-3]
No.
"Calibration Start?" is displayed. After ensuring no
1 possibility of hazard even after actuator operate, press
"OK",
PID automatic
automatically. "Span Calibration is now in Progress" is
2
displayed.
Confirm "Cal Error Status" after actuator operation stopped.
3
If display is "No Error", adjustment is completed.
＊
6
4mADC and 20mADC of input current can be calibrated. This is
not necessary usually.
6: For adjustment procedure, see "5. Input current calibration" of
"■Initial Adjustment".
Procedure
Procedure
adjustment
3131
starts, and operates
No.IP8S-OM00013
A
