Note 1) Checking frequencies are listed as guides. Actually, they may vary depending on how often
you use stages.
3-2．Lubrication
How you lubricate will affect the life and smooth movement of the motorized stage.
Check for the lubrication in daily maintenance.
(1) Lubrication in moving parts
See the Lubrication List and periodically oil/grease the moving parts of the
motorized stage.
Oil/Grease sliding parts even if they are not listed.
(2) Notes on Lubrication
1,Check if moving parts are oiled/greased sufficiently.
2,Check if lubricants have not degraded.
3,Periodically oil or grease by referring to the frequencies we are citing in the
Lubrication List.
4, Make sure you are using correct oil/grease.
(3) Lubrication List (typical list for high-rigidity, high-precision motorized stage)
No.
1
2
3
Check and Maintenance
See our latest catalog for details
Part
Precision guide
block
(Inner block)
Precision guide
block
(Ball screw)
Other driving parts
Note 1: Lubrication frequencies are listed as guides. Actually, they may
vary depending on how often you use stages.
Note 2: A grease by THK CO., LTD.
Note 3: The typical list above covers SGSP/SGMV direct acting series.
Frequency Lubricant Type
Six months Grease
*2
* 1
Six months Grease
*2
* 1
-14-
- 14 -
Remarks
Grease every
30 km of
traveling
Grease every
30 km of
traveling
Depends on
cases
