2-4．Stepping Motor-driven Miniature Actuator
The ACT series stage has a knurled knob at the motor shaft, which allows you to rotate
•
the spindle head manually.
Do not fix actuators so tightly that the body of the stage becomes distorted.
●
Install the stage so that the load is applied in the traveling direction of the spindle.
•
Applying the load from the side of the stage may adversely affect the accuracy and
become the cause failure. Never use a stage with the load applied in the pulling
directions.
Use the attached nuts to mount the stage onto your device or assemble it into equipment.
•
In any other methods of fixing, never apply unnecessary load to the stage. Applying
unnecessary load may cause an overload or malfunctions.
Notes on Use
